(888) 312-8812 Login SignupGATES 32308 HOSE CLMP
$350
Limited availability at this price!
In Stock
Get it by Wednesday, Dec 31
GATES 32308 Part Description
Manufacturer
Product Description
Green Stripe Silicone Hose Clamp
Features & Benefits
- 300 series stainless steel band, screw and housing resist corrosion
- Four-piece construction and 100 percent mechanical interlock for added strength and torque capability
- Combination 5/16 in. hexagon with deep slot screw head makes installation easy - tightens with a screwdriver, nut driver or socket wrench
- Wide 9/16 in. band gives 12-1/2 percent more compression than 1/2 in. band
- One-piece band and liner
- Inner-liner band eliminates hose cover extrusion
GATES 32308 Specifications
Product Attributes
| Adjustment Type | Silicone Hose Clamp |
| Hose Clamp Size | 8 |
| Hose Minimum Inside Diameter | .3125 IN |
| Hose Maximum Inside Diameter | .5 IN |
| Minimum Clamping Length | .4375 IN |
| Maximum Clamping Length | 1 IN |
| Band Width | .5625 IN |
| Screw Type | .3125 in. Deep Slot Hex-Head |
| Recommended Torque | 30-40 PPI |
| Maximum Torque | 60 IA |
| Material | Stainless Steel |
| Housing Material | Stainless Steel |
| Band Width | 14 MM |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 7326908688 |
| UPC | 00072053188752 |
| VMRS Code | 053008020 |
| UNSPSC | 31162900 |
GATES 32308 Part Interchanges
| Brand | Part Number |
|---|---|
| ACDelco | 32308C |
| Dayco | 92208 |
| Continental Belt | 51208 |
| Ideal Tridon | 6508790, 6508E51, 6708M, 6708M51 |
| NAPA Belts/Hose | 32308 |
GATES 32308 Cross References
We have 1 alternatives for the 32308 by GATES:
