Gates 28461 - Molded 90 Degree Heater Hose
$1399
MSRP: $15.52
Save: $1.53
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
GATES part description
Product Description
Molded 90 Degree Heater Hose
Application Summary
2006-02 Suzuki, XL-7, V-6 2.7 L, Pipe-1 To W.P.
Features & Benefits
- Resists electrochemical degradation and water permeation
- Use with heater hose connectors and bulk heater hose to create custom assemblies
- Compatible for coolant, air and water applications
- EPDM tube and cover, synthetic fiber reinforcement
- SAE 20R3 EC Class D1, SAE 20R4 EC Class D1
- Temperature Range: -40 Deg. F to +275 Deg. F (-40 Deg. C to +135 Deg. C)
- Caution: Do not use for fuel or oil transfer applications
Product Attributes
| Centerline Length | 16 IN |
| 9845 | 0 |
| Arm Length | 12 IN |
| End 1 Inside Diameter | .5 in |
| End 2 Inside Diameter | .5 in |
| Angle | 90 |
| Material | EPDM |
| 9839 | Yes |
| Centerline Length | 406 MM |
| 5034 | 305 MM |
| End 1 Inside Diameter | 13 MM |
| End 2 Inside Diameter | 13 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 4009310000 |
| Country of Origin (Primary) | US |
| UPC | 00072053061956 |
| VMRS Code | 042010004 |
| UNSPSC | 40142000 |
Part Interchanges
- ACDelco 16197M
- Dayco 80394
- Dayco D80394
- Carquest 28461
- Chrysler 3441275
- Chrysler 55035861
- Datsun/Nissan 27182H8500
- General Motors 30025044
- Suzuki 1787377E01
- Suzuki 1787173X50
- Suzuki 1787183010
- Toyota 8724589168
- Toyota 8724589186
- Toyota 8724590A04
- Honda 19504PV1A00
- Mazda KJ01-15-381
- Mazda KJ02-15-381
- Mazda KJ0215381A
- Goodyear 63712
- NAPA Belts/Hose 9802
- Duralast D80394
Fits Vehicles
- Suzuki Vitara (2004)
- Chevrolet Tracker (2001-2004)
- Pontiac Firefly (1994)
- Toyota Pickup (1984)
- Mazda Millenia (1995-2002)
- Toyota Land Cruiser (1979-1987)
- Toyota 4Runner (1984)
- Nissan 210 (1980-1982)
- Acura Vigor (1992-1994)
- Geo Metro (1993-1994)
- GMC P3500 (1987-1990)
- Chevrolet P30 (1987-1990)
- Isuzu Impulse (1988-1989)
- Suzuki XL-7 (2002-2006)
- Suzuki Samurai (1989-1995)
- Suzuki Grand Vitara (1999-2005)
