(888) 312-8812 Login SignupGATES 28326 Green Stripe Wire Inserted Straight Coolant Hose
Tap to view 2 more
$31449
Limited availability at this price!
5 Day Lead Time
Get it by Thursday, Jan 29
GATES 28326 Part Description
Manufacturer
Product Description
Green Stripe Wire Inserted Straight Coolant Hose
Features & Benefits
- Heavy-duty fabric reinforcement with helical carbon steel wire
- Engineered with compounds which resist electrochemical degradation
- Exceeds SAE 20R2 Type EC (Class D2 tube and cover) except in vacuum applications
- Temperature Range: -40 Deg. F to +257 Deg. F (-40 Deg. C to +125 Deg. C)
- Note: Long spans must be supported every 3 feet
- Caution: Do not use for fuel or oil transfer applications
GATES 28326 Specifications
Product Attributes
| Centerline Length | 10 FT |
| End 1 Inside Diameter | 1.625 in |
| End 2 Inside Diameter | 1.625 in |
| Working Pressure | 75 PS |
| Vacuum Rating | 20 INHG |
| Bending Radius | 3.5 in |
| Construction | 1-Ply |
| Material | EPDM |
| Molded | No |
| Centerline Length | 3.05 LM |
| Centerline Length | 120 IN |
| Centerline Length | 3048 MM |
| End 1 Inside Diameter | 41 MM |
| End 2 Inside Diameter | 41 MM |
| Bending Radius | 89 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 4009410000 |
| Country of Origin (Primary) | US |
| UPC | 00072053177640 |
| VMRS Code | 042004050 |
| UNSPSC | 40142000 |
