Gates 26522 - Green Stripe Heavy-Duty Vulco-Flex Coolant Hose
$3949
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
GATES part description
Product Description
Green Stripe Heavy-Duty Vulco-Flex Coolant Hose
Application Summary
1989-1971 Ford, LN8000, Caterpillar 3208 Diesel, Lower
Features & Benefits
- Engineered to resist electrochemical degradation, the leading cause of hose failure
- Built-in steel spiral wire allows for medium sized curves without kinking or collapsing
- EPDM tube and Neoprene cover for extended service life
- Polyester fabric-ply reinforcement vulcanizes into shape without unnecessary strain on connections
- Resistant to heat, oil and ozone
- Performs to SAE 20R5 Type EC Class D-2 specifications
- Temperature Range: -40 Deg. F to +257 Deg. F (-40 Deg. C to +125 Deg. C)
- Caution: Do not use for fuel or oil transfer applications
Product Attributes
| Centerline Length | 17 IN |
| End 1 Inside Diameter | 2.25 in |
| End 2 Inside Diameter | 2.25 in |
| Material | EPDM, Steel |
| 9839 | No |
| Centerline Length | 432 MM |
| End 1 Inside Diameter | 57 MM |
| End 2 Inside Diameter | 57 MM |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 4009410000 |
| UPC | 00072053064926 |
| VMRS Code | 042004061 |
| UNSPSC | 40142000 |
Part Interchanges
- Mopar BH-639
- Motorcraft KE-170
- White 1700990
- White 1711023
- White 1716917
- White 1716919
- White 1726175
- White 1728991
- White 1735357
- White 549F2
- White N66204C
- ACDelco 31721
- Dayco 2117HD
- Dayco 82191
- Dayco 82191GL
- Dayco M57
- BF Goodrich 917
- CARQUEST 26522
- Case Tractor 78248
- Case Tractor A15490
- Caterpillar A628392C4
- Chrysler 2506022
- Chrysler 2506565
- Chrysler 2514230
- Chrysler 3820587
- Clark Equipment PGF16127
- Diamond Reo 997F22
- Epton 917
- General Motors 2090095
- General Motors 5112791
- General Motors 650323
- General Motors 650324
- General Motors 678944
- International Harvester (IHC) 175726
- International Harvester (IHC) 189379R11
- International Harvester (IHC) 2070935C1
- International Harvester (IHC) 207803R11
- International Harvester (IHC) 270935C1
- International Harvester (IHC) 305633R1
- International Harvester (IHC) 680006R1
- International Harvester (IHC) 694639R3
- John Deere T39798
- Reo Trucks 972F223
- Reo Trucks 972F256
- Reo Trucks 972F26
- Pacific Car & Foundry K181C678
- Mack 10MF29301P16
- Mack 11MF2320P22
- Mack 512122
- Goodyear 53617
- Volvo GM Heavy Truck V1092202
- NAPA Belts/Hose FM57
- Durkee-Atwood 917
- <Unknown> 103368
- <Unknown> 2496331
- <Unknown> 698268
- <Unknown> LL12113
- <Unknown> Y698584
- Continental Belt 53617
Fits Vehicles
- International B110 (1959-1960)
- International B100 (1959-1960)
- Peterbilt 359 (1981)
- International B132 (1959-1960)
- International B130 (1959-1960)
- International B112 (1959-1960)
- International B102 (1959-1960)
- International B122 (1959-1960)
- International B120 (1959-1960)
- Peterbilt 352 (1981)
- Mack RWS (1981-1985)
- Mack RWL (1981-1985)
- Mack RW (1985-1991)
- Peterbilt 362 (1982-1985)
- Peterbilt 349 (1984-1986)
- Mack R (1981-1985)
- Peterbilt 282 (1966-1980)
- Ford LN8000 (1981-1983, 1985-1989)
- Ford LTS8000 (1981-1989)
- Ford LT8000 (1981-1988)
- Ford LS8000 (1988-1989)
- Ford LNT8000 (1981-1989)
- Ford L8000 (1981-1988)
- GMC Astro (1981-1988)
