GATES 24936 Part Description
Manufacturer
Product Description
Green Stripe Wire Inserted Straight Coolant Hose
Application Summary
Clark-Lima, 720, Detroit Diesel 8V-71 Diesel, Lower - Lower Structure
Features & Benefits
- Heavy-duty fabric reinforcement with helical carbon steel wire
- Engineered with compounds which resist electrochemical degradation
- Exceeds SAE 20R2 Type EC (Class D2 tube and cover) except in vacuum applications
- Temperature Range: -40 Deg. F to +257 Deg. F (-40 Deg. C to +125 Deg. C)
- Note: Long spans must be supported every 3 feet
- Caution: Do not use for fuel or oil transfer applications
GATES 24936 Specifications
Product Attributes
| Centerline Length | 5 FT |
| End 1 Inside Diameter | 2.25 in |
| End 2 Inside Diameter | 2.25 in |
| Working Pressure | 55 PS |
| Vacuum Rating | 20 INHG |
| Bending Radius | 5.5 in |
| Construction | 1-Ply |
| Material | EPDM |
| Molded | No |
| Centerline Length | 1.52 LM |
| Centerline Length | 60 IN |
| Centerline Length | 1524 MM |
| End 1 Inside Diameter | 57 MM |
| End 2 Inside Diameter | 57 MM |
| Bending Radius | 140 MM |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 4009410000 |
| UPC | 00072053177510 |
| VMRS Code | 042004050 |
| UNSPSC | 40142000 |
GATES 24936 Part Interchanges
| Brand | Part Number |
|---|---|
| ACDelco | 31210 |
| Dayco | 4H225, 75225, 75225GL, 4225, 74225 |
| Carquest | 24936 |
| Goodyear | 58036 |
GATES 24936 Cross References
We have 1 alternatives for the 24936 by GATES:
