(888) 312-8812 Login SignupGATES 22039 Premium Molded Coolant Hose
MSRP: $24.28
$1649
Save $7.79
Limited availability at this price!
In Stock
Get it by Wednesday, Jan 7
GATES 22039 Part Description
Manufacturer
Product Description
Premium Molded Coolant Hose
Application Summary
2004-1988 Chevrolet, S Series Pickup, V-6 4.3 L, Lower
Features & Benefits
- Specifically-engineered materials resist collapse under vacuum
- Specifically-engineered materials resist collapse under vacuum
- Engineered to resist electrochemical degradation, the leading cause of hose failure
- Pre-shaped to fit and to ensure perfectly sealed conditions
- EPDM tube; synthetic fiber knit reinforcement; heat-, ozone- and chemical coolant-resistant EPDM cover
- Meets requirements of SAE 20R4, class D2 and DIN 73411, class A (except for tolerances)
- Temperature Range: -40 Deg. F to +257 Deg. F (-40 Deg. C to +125 Deg. C)
- Note: Gates recommends replacing hose clamps each time a new coolant hose is installed
- Caution: Do not use for fuel or oil transfer applications
GATES 22039 Specifications
Product Attributes
| Centerline Length | 17.8 IN |
| Modular | No |
| Branch Quantity | 0 |
| Quick Connect Fitting Quantity | 0 |
| End 1 Inside Diameter | 1.49 in |
| End 2 Inside Diameter | 1.75 in |
| Contains Spring | No |
| Material | EPDM |
| Molded | Yes |
| Centerline Length | 452 MM |
| End 1 Inside Diameter | 38 MM |
| End 2 Inside Diameter | 44 MM |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 4009310000 |
| UPC | 00072053114966 |
| VMRS Code | 042004014 |
| UNSPSC | 40142000 |
GATES 22039 Part Interchanges
| Brand | Part Number |
|---|---|
| Motorcraft | KM-3339 |
| ACDelco | 22287M |
| Dayco | 71723, C71723 |
| Carquest | 22039 |
| General Motors | 15149147, 15561135, 15651066, 15661066, 15984270 |
| MasterPro | 22039, C2039 |
| Roadmax | C2039 |
| Goodyear | 61502 |
| NAPA Belts/Hose | 8723 |
| Duralast | C71723 |
GATES 22039 Fits Vehicles
- Oldsmobile Bravada (1991-1994, 1996-2001)
- GMC Sonoma (1991-2004)
- GMC S15 (1988-1990)
- GMC Jimmy (1992-2005)
- GMC S15 Jimmy (1988-1991)
- Chevrolet S10 (1988-2004)
- Chevrolet Blazer (1995-2005)
- Chevrolet S10 Blazer (1988-1994)
- Isuzu Hombre (1997-1999)
GATES 22039 Cross References
We have 1 alternatives for the 22039 by GATES:
GATES 22039 Customer Reviews
No reviews yet
Be the first to review this product!
