Gates 22013 - Premium Molded Coolant Hose
$1849
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
GATES part description
Product Description
Premium Molded Coolant Hose
Application Summary
1995-1988 Chevrolet, C & K Series Pickup, V-8 5.7 L, Upper
Features & Benefits
- Specifically-engineered materials resist collapse under vacuum
- Specifically-engineered materials resist collapse under vacuum
- Engineered to resist electrochemical degradation, the leading cause of hose failure
- Pre-shaped to fit and to ensure perfectly sealed conditions
- EPDM tube; synthetic fiber knit reinforcement; heat-, ozone- and chemical coolant-resistant EPDM cover
- Meets requirements of SAE 20R4, class D2 and DIN 73411, class A (except for tolerances)
- Temperature Range: -40 Deg. F to +257 Deg. F (-40 Deg. C to +125 Deg. C)
- Note: Gates recommends replacing hose clamps each time a new coolant hose is installed
- Caution: Do not use for fuel or oil transfer applications
Product Attributes
| Centerline Length | 32.8 IN |
| 9940 | No |
| Branch Quantity | 0 |
| 9845 | 0 |
| End 1 Inside Diameter | 1.27 in |
| End 2 Inside Diameter | 1.52 in |
| Contains Spring | No |
| Material | EPDM |
| 9839 | Yes |
| Centerline Length | 833 MM |
| End 1 Inside Diameter | 32 MM |
| End 2 Inside Diameter | 39 MM |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 4009310000 |
| UPC | 00072053222067 |
| VMRS Code | 042004014 |
| UNSPSC | 40142000 |
Part Interchanges
- Canadian Tire 14-2694-8
- Motorcraft KM-3115
- ACDelco 26225X
- Dayco 71884
- Dayco E71884
- Carquest 22013
- General Motors 15592553
- General Motors 15659484
- MasterPro 22013
- MasterPro C2013
- Roadmax C2013
- Ultralast C2013
- Goodyear 62441
- NAPA Belts/Hose 8698
- Continental Belt 62441
- Duralast D90836
- Continental Belt E90720
- Continental Belt D90836
Fits Vehicles
- Chevrolet Suburban 1500 (1995)
- Chevrolet C3500HD (1991)
- Chevrolet Suburban (1992-1994)
- Chevrolet C35 (1988-1995)
- GMC C3500HD (1991)
- GMC Yukon (1992-1995)
- GMC K3500 (1988-1995)
- GMC K2500 Suburban (1992-1995)
- GMC K2500 (1988-1995)
- GMC K1500 Suburban (1992-1995)
- GMC K1500 (1988-1995)
- GMC C3500 (1988-1995)
- GMC C2500 Suburban (1992-1995)
- GMC C2500 (1988-1995)
- GMC C1500 Suburban (1992-1995)
- GMC C1500 (1988-1995)
- Chevrolet Tahoe (1995)
- Chevrolet K3500 (1988-1995)
- Chevrolet K2500 Suburban (1992-1995)
- Chevrolet K2500 (1988-1995)
- Chevrolet K1500 Suburban (1992-1995)
- Chevrolet K1500 (1988-1995)
- Chevrolet C3500 (1988-1995)
- Chevrolet C2500 Suburban (1992-1995)
- Chevrolet C2500 (1988-1995)
- Chevrolet C1500 Suburban (1992-1995)
- Chevrolet C1500 (1988-1995)
- Chevrolet Blazer (1992-1994)
