Gates 21897 - Premium Molded Coolant Hose
$2599
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
GATES part description
Product Description
Premium Molded Coolant Hose
Application Summary
1994-1990 Ford, Ranger, V-6 4.0 L, Upper
Features & Benefits
- Specifically-engineered materials resist collapse under vacuum
- Specifically-engineered materials resist collapse under vacuum
- Engineered to resist electrochemical degradation, the leading cause of hose failure
- Pre-shaped to fit and to ensure perfectly sealed conditions
- EPDM tube; synthetic fiber knit reinforcement; heat-, ozone- and chemical coolant-resistant EPDM cover
- Meets requirements of SAE 20R4, class D2 and DIN 73411, class A (except for tolerances)
- Temperature Range: -40 Deg. F to +257 Deg. F (-40 Deg. C to +125 Deg. C)
- Note: Gates recommends replacing hose clamps each time a new coolant hose is installed
- Caution: Do not use for fuel or oil transfer applications
Product Attributes
| Centerline Length | 26 IN |
| 9940 | No |
| Branch Quantity | 0 |
| 9845 | 0 |
| End 1 Inside Diameter | 1.25 in |
| End 2 Inside Diameter | 1.38 in |
| Contains Spring | No |
| Material | EPDM, Plastic |
| 9839 | Yes |
| Centerline Length | 660 MM |
| End 1 Inside Diameter | 32 MM |
| End 2 Inside Diameter | 35 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 4009310000 |
| Country of Origin (Primary) | US |
| UPC | 00072053135060 |
| VMRS Code | 042004014 |
| UNSPSC | 40142000 |
Part Interchanges
- Canadian Tire 14-2637-2
- Charter C1897
- Motorcraft KM-1823
- Motorcraft KM-1824
- Bravo C1897
- ACDelco 22255M
- Dayco 71534
- Dayco 71913
- Dayco D71534
- Dayco D71913
- Dayco 71531
- Dayco E71531
- Carquest 21897
- MasterPro 21897
- MasterPro C1897
- Ford F07A 8B274 AC
- Ford F07A 8B274 CC
- Ford F09A 8B274 BE
- Ford F0TZ 8260 A
- Ford F0TZ 8260 B
- Ford F17A 8B274 LA
- Ford F17A 8B274 MA
- Ford F19A 8B274 SA
- Ford F1TA 8B274 LA
- Ford F27A 8B274 TA
- Ford F27A 8B274 UA
- Ford F29A 8B274 SA
- Ford F2TA 8B274 TA
- Ford F69A 8B274 JA
- Mazda ZZL015186
- Mazda ZZL115186
- Roadmax C1897
- Trugrip 2176
- Ultralast C1897
- Goodyear 467
- Goodyear 61613
- Goodyear 468
- Goodyear 61614
- NAPA Belts/Hose 8587
- Atlas 642325
- Atlas MC212
- Duralast E71531
GATES 21897 Cross Reference
We have 2 alternatives for the 21897 by GATES:
Fits Vehicles
- Mazda B4000 (1994)
- Mazda Navajo (1991-1994)
- Ford Ranger (1990-1994)
- Ford Explorer (1991-1994)
California Proposition 65 Warning
California Proposition 65 Warning
WARNING: This product can expose you to chemical which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov. (Read more)
