Name: Dana 5-1-02710 1610 Series Drive Shaft Companion Flange - Steel, 2.114 in. Major dia., 4 Holes
SKU: 5102710
Price: 426.49 USD
Availability: InStock

DANA part description

Specifications

Brand	Spicer
Series	1610
Major Diameter (D) In.	2.114
Spline Count	32 I
Involute Spline	Y
Pilot Diameter (C) In.	FEMALE
Bolt Circle Dia.(B) In.(FL YK)	5.118
Bolt Hole Diameter In (FL YK)	.512
Number Of Holes (FL YK)	4
Ground Hub Diameter In.	3.000
Length Thru Hole (F) In.	2.250
Flange Face To End Of Hub (G)	3.500
Companion Flange Assembly	N
Material	Steel
VMRS	024002040
Package Type	EACH
Package Qty	1
Weight	3.19 LB
Country of Origin	United States

Features & Benefits

Genuine OE quality. Tested and proven.
Built to meet OE standards set by Dana.
Tested and validated to rigorous OE specifications.
Latest production upgrades ensure genuine Spicer parts are as good or better than the OE parts they replace.

Product Attributes

Series	1610
Spline Count	32 I
Major Diameter (D) In.	2.114 IN

Additional Information

Country of Origin (Primary)	US
Harmonized Tariff Code (Schedule B)	8708990000
Harmonized Tariff Code (HTS)	8708990000
UPC	00023913329631
VMRS Code	024002040

Part Interchanges
