Dana 36113-28 - Drive Axle Shaft Assembly - Left, Steel, 40.75 in. Length, 35 Spline, DANA 70 Axle
$83399
In stock
limited availability at this price!
. Learn more
DANA part description
| Axle Model: | DANA 70 |
| Material: | Steel |
| Axle Cover Bolt Hole Qty: | 10 |
| Location: | LH |
| Axle Length: | 40.750 in. |
| Spline Count: | 35 |
| Axle Spline Count: | 35 |
| Bolt Pattern: | 8 x 3.96 |
| Wheel Stud Hole Diameter (IN): | 0.450 |
| Brake Pilot Diameter (IN): | 3.126 |
| Bearing Pilot Diameter (IN): | 1.375 |
| Axle Shaft Included: | Y |
| Axle Type: | Complete Assembly |
| Full-Floating Or Semi-Floating: | Full-Floating |
| Inner Axle Included: | Y |
| Number of Wheel Lugs: | 8 |
| Outer Axle Included: | Y |
| Quantity: | 1 |
Features & Benefits
- Genuine OE quality. Tested and proven.
- Ultrasonically tested for internal cracks that magnetic testing can miss.
- Precision manufacturing processes
- Built from high grade steel that stands up to any grade on the market.
- Engineered for consistent quality and durability
- Engineered for consistent quality and durability.
- Meets Dana aftermarket requirements for static ultimate strength, torsional fatigue and rotating/bending torque
Product Attributes
| Axle Model | DANA 70 |
| Material | Steel |
| ABS/Non-ABS | Non-ABS |
| Length (In) | 40.750 IN |
| Location | LH |
| Spline Count | 35 Inboard |
| Axle Spline Count | 35 Inboard |
| Axle Cover Bolt Hole Qty | 10 |
| Axle Length (In) | 40.750 IN |
| Bearing Pilot Diameter (In) | 1.375 IN |
| Bolt Pattern | 8 X 3.96 |
| Brake Pilot Diameter (In) | 3.126 IN |
| Includes Tone | N |
| Wheel Stud Hole Diameter (In) | 0.450 IN |
| Cover Bolt Quantity | 10 |
| Axle Type | Complete Assembly |
| Quantity | 1 |
| Length (mm) | 1035.050 mm |
| ABS Sensor Ring Installed | N |
| Axle Shaft Included | Y |
| Bearing Included | N |
| Full-Floating Or Semi-Floating | Full-Floating |
| Inner Axle Included | Y |
| Number Of Wheel Lugs | 8 |
| Outer Axle Included | Y |
| Retainer Ring Included | N |
| Seal Included | N |
| Seal Kit Included | N |
| U-Joint Included | N |
| Wheel Bearing Included | N |
| Wheel Bolt Prep Kit Included | N |
| Wheel Nuts Included | N |
| Wheel Studs Included | N |
| Axle Length (Mm) | 1035.050 MM |
| ABS Tone Ring Included | No |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 8708508500 |
| Harmonized Tariff Code (HTS) | 8708508500 |
| UPC | 00023913134266 |
Part Interchanges
Fits Vehicles
- Ford E-350 Super Duty (2004-2006)
- Ford E-350 Econoline Club Wagon (1992-2002)
- Ford E-350 Club Wagon (2003-2005)
- Ford E-350 Econoline (1992-2000)
- Ford E-250 Econoline (1992-2001)
- Ford E-150 Econoline Club Wagon (1992-2001)
- Ford E-150 Econoline (1992-2001)
