Name: Dana 100-4-02875-1X PINION SHAFT END YOKE
SKU: 1004028751x
Price: 271.49 USD
Availability: InStock

DANA part description

END YOKE ASSY

Dana Holding Corporation Spicer SPL100 Series End Yoke Assembly

The Dana Holding Corporation Spicer SPL100 Series end yoke efficiently links the transmission to the drive axle. Installing this component addresses the signs of a failing yoke and u-joint, which include squeaking noise when moving forward or reverse, vibration when running at high speeds, and many others.

Features & Benefits

Top-quality SPL100 series pinion shaft end yoke
Durably engineered to improve a vehicle or a construction equipment’s performance and efficiency
Integrates cutting-edge technologies to make a vehicle or machine more productive on the job site
Meets strict quality standards for dependable functionality even under the harshest operating environment
Backed by the company’s over 115 years of innovation and technological revolutions

Product Attributes

Series	SPL100
Material	Steel
Spline Count	41
Type	Splined Hole
Assembly	Y
Hub Diameter R	3.000 IN
Includes Slinger/Plug	Y
Involute Spline	Y
Length Thru Hole Q	2.166 IN
Outside Yoke Dimension (In) E	5.375 IN
Yoke Bearing Dimension (In) D	1.625 IN
Yoke Style	BS
Major Diameter	2.143 IN
C/L To End Hub S	4.310 IN
C-Bore Depth	0.310 IN

Additional Information

Country of Origin (Primary)	MX
Harmonized Tariff Code (Schedule B)	8708990000
Harmonized Tariff Code (HTS)	8708990000
UPC	00023913325084
VMRS Code	022003072

Part Interchanges
