Dana 3-53-02410 - Drive Shaft Midship Stub Shaft - For Use With Outboard Slip Yoke
$12799
In stock
limited availability at this price!
. Learn more
DANA part description
| For Use With: | Outboard Slip Yoke |
| Series: | 1310-1410 |
| Material: | Steel |
| Spline Outside Diameter: | 1.4370 in. |
| Number of Splines: | 21/22 I |
| Involute: | Y |
| Fits Tube Diameter: | 3.5 in. |
| Fits Tube Wall: | 0.083 |
| Spline End to Brg Shoulder (Y): | 7.492 |
| Spline End to Weld (K) In.: | 8.240 |
| Spline Length (L) In.: | 3.500 |
| Shoulder Diameter (B) In.: | 1.690 |
| Shoulder Length (G) In.: | 0.500 |
| Bearing Diameter (C) In.: | 1.575 |
| Butt Diameter: | 3.345 |
| Style: | 2 |
| Bearing Diameter (Max): | 1.5752 |
| Bearing Diameter (Min): | 1.5747 |
| Bearing Diameter Length: | 1.375 |
| Bearing Diameter Radius: | 0.19 |
Dana Holding Corporation Spicer Driveshaft Midship Stub Shaft
Developed, manufactured, and tested by the world leader in driveshaft technology, the Dana Holding Corporation Spicer driveshaft midship stub shaft delivers the most efficient and dependable performance on the road. This component showcases an innovative, industry-leading design to meet the demands of every commercial vehicle application.
Features & Benefits
- Made in the USA
- Loaded with advanced and industry-proven features for superior functionality
- Highly resistant to corrosion and regular wear
- Tested in Dana’s on- and off-road test tracks to ensure reliability in extreme operating conditions
- Spicer products are designed to the same exacting standards as specified by OEMs
- Directly replaces a bad midship stub shaft to restore the driveshaft to proper working order
Features & Benefits
- Dana manufactured Spicer components are designed, engineered, tested, and manufactured to meet or exceed OE requirements.
- Spicer components are engineered to meet or exceeds the performance requirements of the original factory driveline component
- Tested for unparalleled reliability
- Strength and durability for long life
Product Attributes
| Series | 1310-1410 |
| Material | Steel |
| Style | 2 |
| Fits Tube Diameter | 3.5 IN |
| Number of splines | 21/22 I |
| Involute | Y |
| Fits Tube Wall | 0.083 IN |
| Butt Diameter | 3.345 IN |
| Bearing Diameter (C) In. | 1.575 IN |
| Bearing Diameter (Max) | 1.5752 IN |
| Spline End To Weld (K) In. | 8.240 IN |
| Spline Length (L) In. | 3.500 IN |
| Spline O.D. | 1.4370 IN |
| Bearing Diameter (Min) | 1.5747 IN |
| For Use With | Outboard Slip Yoke |
| Shoulder Diameter (B) In. | 1.690 IN |
| Shoulder Length (G) In. | 0.500 IN |
| Spline End To Brg Shoulder (y) | 7.492 |
| Bearing Diameter Length | 1.375 IN |
| Bearing Diameter Radius | 0.19 IN |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 8708990000 |
| Harmonized Tariff Code (HTS) | 8708990000 |
| UPC | 00023913328627 |
| VMRS Code | 024002060 |
Part Interchanges
Dana Holding Corporation® is an internationally known company specializing in drivetrain and e-Propulsion systems. It conceptualizes, manufactures, and supplies energy-management and power- and conveyance solutions for the present-day and future vehicles and trucks. With its over 115 years of industry experience and innovation, and despite several turbulences the automotive and trucking industry has been through, Dana has managed to take the lead in revolutionary technological inventions. Dana Holding Corporation comprises different world-renowned brands catering to various market segments. These include SPICER Drivetrain Systems, VICTOR REINZ Sealing Products, LONG Thermal Products, BREVINI Motion Systems, GRAZIANO High-Performance Transmissions, FAIRFIELD Custom Gears and Drives, and a lot more.
