FRAM CH5320 Part Description
Manufacturer
Product Description
FRAM, CH5320, Oil Filter
Features & Benefits
- Proven protection for up to 10,000 miles (16,000 kilometers)
- Engineered for use with synthetic or conventional motor oils
- Filter media is a blend of fiber and resin that captures 95% of the dirt particles
- The perfect balance of dirt-trapping efficiency and dirt-holding capacity
- Includes gaskets and O-rings manufactured to endure the high pressures and high temperatures in today’s engines
Cartridge Oil Filter
FRAM CH5320 Specifications
Product Attributes
| Filter Media Material | Cellulose/Synthetic Blend |
| Height | 4.343 IN |
| Grade Type | Regular |
| Gasket Or Seal Included | Yes |
| Filter Type | Cartridge |
| Non Slip Grip | No |
| Anti-Drain Back Valve | No |
| Bypass Relief Valve | No |
| Gasket Inside Diameter | 1.142 IN |
| Gasket Outside Diameter | 1.378 IN |
| Gasket Thickness | 0.354 IN |
| Gasket Type | Gasket |
| Grade | Advanced |
| Housing Color | NA |
| Inside Diameter Bottom | 1.125 IN |
| Meets Or Exceeds Original Equipment Manufacturer Specifications | Yes |
| New Or Remanufactured | New |
| O-ring (1) Inside Diameter | 0.177 IN |
| O-ring (1) Outside Diameter | 0.236 IN |
| O-ring (1) Thickness | 0.059 IN |
| O-ring Inside Diameter | 3.563 IN |
| O-ring Outside Diameter | 3.720 IN |
| O-ring Thickness | 0.157 IN |
| O-Rings Included | Yes |
| Outer Diameter Bottom | 4.343 in |
| Outer Diameter Top | 4.343 in |
| Replacable Filter | Yes |
| Reusable | No |
| Top Inside Diameter | 1.125 in |
| Torque Nut | No |
| Washable | No |
| Washer (1) Inside Diameter | 0.472 IN |
| Washer (1) Outside Diameter | 0.630 IN |
| Washer (1) Thickness | 0.039 IN |
| Washer (2) Inside Diameter | 0.394 IN |
| Washer (2) Outside Diameter | 0.551 IN |
| Washer (2) Thickness | 0.039 IN |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8421230000 |
| Warranty Special | See Rep |
| Warranty Special UOM | SR |
| Warranty Time | 30 |
| Warranty Time UOM | DA |
| UPC | 00009100382580 |
| UNSPSC | 15121501 |
FRAM CH5320 Part Interchanges
| Brand | Part Number |
|---|---|
| Beck/Arnley | 041-0787, 041-8103 |
| Champ | P834 |
| Bosch | 72192 |
| Hastings | LF301 |
| Promotive | PH8812 |
| Group 7 | V8812 |
| Pro-Tec | 195 |
| ACDelco | PF2139 |
| Kralinator | L650 |
| Purolator | L28812 |
| Quaker State | QS5320 |
| Wix | 51160 |
| Big A | 92160 |
| Firestone | P834 |
| Baldwin | P7088 |
| LUBER-FINER | P834 |
| Carquest | 85160 |
| VIPER | 5320 |
| Shell - Archived | L28812 |
| Mann-Filter | H926/3X, HU926/3X, HU926/4X |
| BMW | 11 42 1 730 389, 11 42 7 833 769 |
| Cenex | CO834 |
| Crosland | 1030 |
| Deutsch | D436 |
| Warner | P834 |
| Champion | COC5320 |
| Installer Edge | AL5320 |
| Jiffy Lube | HL5320, JL8812 |
| Knecht | OX68 |
| Mileguard | MO5320 |
| Pronto | VO-130, PO-8812 |
| Pentius | PCB5320 |
| Silverline | 21160 |
| Performax | PO-136 |
| Grand Prix | P834 |
| Parts Master | 61160 |
| Premium Guard | PG8812 |
| MAHLE | OX187D, OX68D |
| NAPA | 1160 |
| FVP | G1160 |
| Mobil | L28812 |
| Car Care | OF5320 |
| Mighty Distributing System | L28812, M8812 |
| Canada Tire | 17-1739-0 |
| GK Industries | EF28812 |
| Mahle | OX187D, OX68D |
| Citgo Petroleum | P834 |
| Factory Motor Parts | G1160 |
| STP Filters | S5320 |
| MicroGard | MGL51160 |
| Valvoline | LC-834, VO-130 |
| Champion Filters | COC5320 |
| Security Filters | P834 |
| Warner Filters | P834 |
| MicroGard Select | MSL51160 |
| Premium Guard Extended Life | PG5690EX |
FRAM CH5320 Fits Vehicles
- Suzuki Aerio (2002)
- BMW 525iT (1993)
- BMW 320i (1992-1995)
- BMW Z4 (2006-2008)
- BMW Z3 (1998-2002)
- BMW M3 (1994-1999, 2001-2006)
- BMW 325i (1992-1995)
- BMW 525i (1991-1995)
- BMW 325is (1992-1995)
FRAM CH5320 Cross References
We have 10 alternatives for the CH5320 by FRAM:
