Name: Weatherhead PT24004NA-500R Eaton Weatherhead PT240 Series Thermoplastic Specialty Hose and Tubing
SKU: pt24004na500r
Price: 255.0 USD
Availability: InStock

WEATHERHEAD part description

Abrasion Resistance	Premium
Application	Liquid and gas.
Bend Radius Min	0.75 inch
Burst Pressure	600 psi
Color	Natural
Conductivity	Conductive
Construction	Extruded
Cover Material	Polyethelene
Dash Size	-4
InsIDe Diameter	0.12 inch
Lay Line Style	Ink Jet
Length Configuration	100, 500, 1000
OutsIDe Diameter	0.25 inch
Package Form	Reel
Qualified Hose Fittings	Minibarb, Polyline, SelfAlign, Compression with 2030 insert, Push to Connect, Push to Connect Flow Controls, Push to Connect Plus, Molded Compression
Reinforcement Material	UV Stabilized
Tube Material	Polyethylene
Tube Wall Thickness	0.062 inch
Working Pressure	200 psi
Working Temperature Max	135 degree Fahrenheit
Working Temperature Min	-40 degree Fahrenheit

Features & Benefits

UV resistance last longer than all competitors
Hundreds of styles to choose from
Rugged enough to stand up to the toughest applications

Officially acquired by Eaton in 2002, Weatherhead® is one of the industry’s biggest suppliers of hydraulic hose, hose ends, tube fittings, couplings, assembly equipment, and support accessories. Weatherhead crafts top-products that are widely used in mining, agriculture, construction, truck, and bus applications. Eaton delivers Weatherhead thermoplastic tubing in different sizes—from 1/8 to 1 inch—designed for use in air tools, robotics, beverage dispensing as well as air and water supply. Driven by the company’s goal to offer unique solutions to a wide range of markets that enable businesses to be at the forefront of change, Weatherhead remains the truck industry’s leading source of premium-quality hoses, fittings, and adapters for your fleet’s hose and fittings needs
