TRIANGLE SUSPENSION part description

Inventory Available

DUB OKC FON Unit Price
102 5 47
Type Bellows # Top Plate # Bottom Plate # Bottom Plate Material
Rolling Lobe 101015
1DK25B
1T17B5
566263050
6390
Plastic
Top Plate Dia. (in) Design Height (in) Min. Height (in) Max. Height (in)
10.0 10.0 5.9 19.3
Max. Diameter (in) Load (lbs) @ 80psi Load (lbs) @ 100psi Natural Frequency (cpm)
13.9 7400 9250 81

2 Schematics

Hendrickson Model- INTRAXX AA230T, AA250T - Trailer Suspension
Hendrickson Models-VANTRAXX HKA180, HKA200, HKA250 - Trailer Suspension

Cross Reference

OEM # - Xref # Manufacturer
101015P460 ContiTech
1DK25B8751 Phoenix
AB1DK25A8709 Phoenix
AS8453
AS8709 Firestone
C20900 Hendrickson
FS8751 Firestone
RL87510 Road Leveler
W013588709 Firestone
W013588751 Firestone
Hendrickson Model- INTRAXX AA230T, AA250T - Trailer Suspension

Since 1919, Triangle Suspension Systems Co.® has set the gold standard for steel leaf springs. With generations of spring shop customers going back for more than 7 decades, Triangle Suspension has made a name for itself for its use of high-quality materials that are backed by ISO-compliant manufacturing processes. Their catalog covers a wide range of applications, including leaf spring assemblies, air beams, and helper springs for light, medium, and heavy duty vehicles. They also offer spring repair components and custom-engineered spring to fill almost any niche. All their products are manufactured in-house in their DuBois, PA, manufacturing facility and distributed across the United States and beyond.
