TRIANGLE SUSPENSION part description

Inventory Available

DUB OKC FON Unit Price
2 9 1
Type Bellows # Top Plate # Bottom Plate # Bottom Plate Material
Rolling Lobe 1DK23K
1T15M6
566243038
6363
91016
Plastic
Top Plate Dia. (in) Design Height (in) Min. Height (in) Max. Height (in)
9.0 11.0 6.0 21.0
Max. Diameter (in) Load (lbs) @ 80psi Load (lbs) @ 100psi Natural Frequency (cpm)
12.6 5900 7500 71

Cross Reference

OEM # - Xref # Manufacturer
1DK23K9296 Phoenix
1R12400 Goodyear
8061151 Volvo
8169868 Volvo
91016P416 ContiTech
AB1DK23K9296 Phoenix
AS9296 Firestone
FS9296 Firestone
RL92960 Road Leveler
SC2760 Loadguard
W013589296 Firestone

Since 1919, Triangle Suspension Systems Co.® has set the gold standard for steel leaf springs. With generations of spring shop customers going back for more than 7 decades, Triangle Suspension has made a name for itself for its use of high-quality materials that are backed by ISO-compliant manufacturing processes. Their catalog covers a wide range of applications, including leaf spring assemblies, air beams, and helper springs for light, medium, and heavy duty vehicles. They also offer spring repair components and custom-engineered spring to fill almost any niche. All their products are manufactured in-house in their DuBois, PA, manufacturing facility and distributed across the United States and beyond.

Don't know your part number?

Take a photo and we'll identify it!
