| DUB | OKC | FON | Unit Price |
|---|---|---|---|
| 1 | 1 | 1 | |
| Type | Bellows # | Top Plate # | Bottom Plate # | Bottom Plate Material | |
|---|---|---|---|---|---|
| Rolling Lobe | 1DK23L 1T15M9 566243066 6364 91019 | Plastic |
| Top Plate Dia. (in) | Design Height (in) | Min. Height (in) | Max. Height (in) |
|---|---|---|---|
| 9.0 | 15.0 | 7.9 | 24.6 |
| Max. Diameter (in) | Load (lbs) @ 80psi | Load (lbs) @ 100psi | Natural Frequency (cpm) |
| 12.6 | 5640 | 7160 | 61 |
| OEM # - Xref # | Manufacturer |
|---|---|
| 1003589245C | Ridewell |
| 1DK23L9245 | Phoenix |
| 1R12265 | Goodyear |
| 1R12446 | Goodyear |
| 91019P390 | ContiTech |
| AS9245 | Firestone |
| FS9245 | Firestone |
| RL92450 | Road Leveler |
| SC2134 | Loadguard |
| W013589245 | Firestone |
| Brand | Part Number |
|---|---|
| 91557007, AS9245 | |
| CONTITECH | 91019P390 |
| FIRESTONE | FS9245, W013589245 |
| GOODYEAR | 1R12265, 1R12446 |
| LOADGUARD | SC2134 |
| PHOENIX | 1DK23L9245 |
| RIDEWELL | 1003589245C |
| ROAD LEVELER | RL92450 |
Be the first to review this product!
Since 1919, Triangle Suspension Systems Co.® has set the gold standard for steel leaf springs. With generations of spring shop customers going back for more than 7 decades, Triangle Suspension has made a name for itself for its use of high-quality materials that are backed by ISO-compliant manufacturing processes. Their catalog covers a wide range of applications, including leaf spring assemblies, air beams, and helper springs for light, medium, and heavy duty vehicles. They also offer spring repair components and custom-engineered spring to fill almost any niche. All their products are manufactured in-house in their DuBois, PA, manufacturing facility and distributed across the United States and beyond.
