TRIANGLE SUSPENSION part description

Inventory Available

DUB OKC FON Unit Price
12 4 5
Type Bellows # Top Plate # Bottom Plate # Bottom Plate Material
Double Convoluted 22C
578923309
6316
FD33022
---
Top Plate Dia. (in) Design Height (in) Min. Height (in) Max. Height (in)
9.0 9.5 4.1 12.0
Max. Diameter (in) Load (lbs) @ 80psi Load (lbs) @ 100psi Natural Frequency (cpm)
12.8 4200 5250 102

Cross Reference

OEM # - Xref # Manufacturer
1003587400C Ridewell
1027519 R&S Truck & Body
1610769000 Freightliner
2726 Granning
2B12309 Goodyear
554788C1 Navistar
693230 Chevrolet / GMC
90557016 SAF Holland
ABSP2B22R7400 Phoenix
AS0003 Watson & Chalin
AS7400 Firestone
FD33022313 ContiTech
FS7400 Firestone
RL74000 Road Leveler
S1013 Hendrickson
SC2020 Loadguard
SP2B22R7400 Phoenix
W013587400 Firestone
Page Model - 1400 Series - Lift Axle

Since 1919, Triangle Suspension Systems Co.® has set the gold standard for steel leaf springs. With generations of spring shop customers going back for more than 7 decades, Triangle Suspension has made a name for itself for its use of high-quality materials that are backed by ISO-compliant manufacturing processes. Their catalog covers a wide range of applications, including leaf spring assemblies, air beams, and helper springs for light, medium, and heavy duty vehicles. They also offer spring repair components and custom-engineered spring to fill almost any niche. All their products are manufactured in-house in their DuBois, PA, manufacturing facility and distributed across the United States and beyond.
