(888) 312-8812 Login SignupWABCO 4729051110 Electronically Controlled Air Suspension (ECAS) Solenoid Valve
Tap to view 3 more
MSRP: $2,325.70
$1,82549
Save $500.21
Limited Availability
Due to limited availability, we will confirm your order and notify you within 1 business day.
WABCO 4729051110 Part Description
WABCO 4729051110 Specifications
Product Attributes
| Voltage | 24 V |
| Mounting | 2 x M8 |
| Multi Nominal Diameter (From Port 1 To X) | 10.0 / 7.0 / 8.7 mm |
| Max. operating pressure | 290.1 psi |
| Size | 253 x 150 x 137 |
| Electrical connection | Bayonet DIN 72585-A1-4.1-Sn/K2, Bayonet DIN 72585-A1-4.2-Sn/K2 |
| Protection class | IP 6K9K |
| Port thread 11 | M22 x 1.5 JED - 388 |
| Port thread 21 | M22 x 1.5 JED - 388 |
| Port thread 25 | M22 x 1.5 JED-388 |
| Port threads | M22 x 1.5 JED-388 |
| Port thread 3 | Silencer 432 407 060 0 |
| Rated current | 320 mA |
| Port thread 24 | M22 x 1.5 JED - 388 |
| Temperature Range | -40°C to +80°C |
| Weight | 9.2153 |
| Port thread 23 | M22 x 1.5 JED - 388 |
| Port thread 26 | M22 x 1.5 JED-388 |
| Port thread 22 | M22 x 1.5 JED - 388 |
| Application | Rear axle |
| Calculated Volume (dm³) | 5.1992 |
WABCO 4729051110 Cross References
We have 8 alternatives for the 4729051110 by WABCO:
WABCO 4729051110 Customer Reviews
No reviews yet
Be the first to review this product!
WABCO 4729051110 Manufacturer Information
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
