WABCO 9700512090 Part Description
WABCO 9700512090 Specifications
Product Attributes
| Max. operating pressure | 145.0 psi |
| Size | 321 x 134 x 124 |
| Distance Between Holes | 130 mm |
| Calculated Volume (dm³) | 5.3337 |
| Medium | Brake fluid SAE J 1703 |
| Length | 309 mm |
| Port thread 12 | M12 x 1.5 |
| Temperature Range | -40°C to +80°C |
| Port thread 22 | M12 x 1.5 |
| Stroke | 26.0 mm |
| Push-rod thread | M12 x 1.0 |
| Weight | 7.1077 |
| Port thread 11 | M16 x 1.5 |
| Test connection | M16 x 1.5 (J) |
| Mounting | 4x Ø 9.0 mm |
| Port Thread 1-4 | M14 x 1.5 ( B ) |
| Port thread 32 | Ø 8.0 mm |
| Port thread 31 | Flap Exhaust |
WABCO 9700512090 Cross References
We have 4 alternatives for the 9700512090 by WABCO:
WABCO 9700512090 Customer Reviews
No reviews yet
Be the first to review this product!
WABCO 9700512090 Manufacturer Information
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
