(888) 312-8812 Login SignupWABCO 4800015000 Electronic Brake Control Module - EBS Brake Signal Transmitter
Tap to view 3 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
WABCO 4800015000 Part Description
WABCO 4800015000 Specifications
Product Attributes
| Size | 239 x 141 x 106 |
| Type | 3 |
| Mounting | 3x M8 |
| Calculated Volume (dm³) | 3.5721 |
| Weight | 3.8757 |
| Max. operating pressure | 145.0 psi |
| Multi Nominal Diameter (From Port 1 To X) | 6 mm |
| Electrical connection | DIN 72585-A1-4.1-Sn/K1, EXTERNAL CONTOUR DIN 72585 NECESSARY SOCKET AMP NO. 0-96-7650-1 |
| Protection class | IP 56, IP 59K |
| Port thread 12 | M22 x 1.5 JED - 388 |
| Port thread 11 | M22 x 1.5 JED - 388 |
| Output Force | 12000 N |
| Thread | Voss threads |
| Application | Paccar, Solaris |
| Silencer | 480 001 520 2 |
| Port thread 3 | Silencer 480 001 520 2 |
| Stroke | 14.0 mm |
| Temperature Range | -40°C to +80°C |
| Port thread 21 | M22 x 1.5 JED - 388 |
| Port thread 22 | M22 x 1.5 JED - 388 |
| Voltage | 8 to 32 V |
| Distance between bolts | 61x61 mm |
WABCO 4800015000 Cross References
WABCO 4800015000 Customer Reviews
No reviews yet
Be the first to review this product!
WABCO 4800015000 Manufacturer Information
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
WABCO 4800015000 Questions & Answers
No questions yet
Be the first to ask a question about this product!
