WABCO 4630840410 Part Description
Manufacturer
Features & Benefits
- Unique variable adjustment mechanism allows for precise control over the lift axle activation pressure threshold
- Optimizes lift axle engagement and disengagement for reduced fuel consumption
- Minimizes unnecessary strain on tires and drivetrain components by raising the lift axle when not required
- Cost-effective solution, providing long-lasting performance and contributing to overall trailer fuel savings
WABCO Lift Axle Control Valve
Optimize your trailer's axle configuration for improved fuel efficiency and handling with the WABCO Lift Axle Control Valve. This component automatically raises or lowers the additional axle based on vehicle weight and operating conditions. It features a unique variable adjustment mechanism that allows for fine-tuning of the activation pressure threshold. This ensures the lift axle engages and disengages at optimal weight points, minimizing unnecessary wear and tear on tires and drivetrain components while maximizing fuel economy. Made with high-quality, corrosion-resistant materials and rigorously tested, the WABCO 4630840410 guarantees reduced wear and tear on tires and drivetrain and efficient trailer operation.
WABCO 4630840410 Specifications
Product Attributes
| Max. operating pressure | 13.0 bar |
| Max. operating pressure | 188.5 psi |
| Size | 194 x 66 x 95 |
| Rated current | 220 mA |
| Port thread 22 | 2x Ø 8 x 1 |
| Temperature Range | -40°C to +65°C |
| Electrical connection | DIN 72585-A1-3.6-Sn/K1 |
| Port thread 31 | Flap exhaust |
| Port thread 11 | Ø 8 x 1 |
| Weight | 1.9202 |
| Port thread 12 | Ø 8 x 1 |
| Voltage | 24 V |
| Actuation | Electrical |
| Type | LACV |
| Protection class | IP 6K9K |
| Version | Single-circuit |
| Calculated Volume (dm³) | 1.2164 |
| Port thread 21 | 2x Ø 8 x 1 |
WABCO 4630840410 Cross References
| Brand | Part Number |
|---|---|
| BENALU | D04656000 |
| DAF | 6502241 |
| GOLDHOFER | 170970 |
| KRONE | 515003124, 515004989 |
| KÄSSBOHRER | 21153104060 |
| KÖGEL | 6502241 |
| LANGENDORF | 1268812 |
| MEILLER | 79903470193565 |
| OTOKAR | AIF1803 |
| SCANIA | 2090294 |
| SCHMITZ | 1118420 |
| SCHWARZMÜLLER | 83604 |
| TIRSAN | 21153104060 |
