(888) 312-8812 Login SignupWABCO 9617231250 Parking Brake Valve - Hand Brake Valve
Tap to view 3 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
WABCO 9617231250 Part Description
WABCO 9617231250 Specifications
Product Attributes
| Max. operating pressure | 159.54 psi |
| Weight | 2.09 |
| Max. operating pressure | 11.0 bar |
| Temperature Range | -40°C to +80°C |
| Size | 179 x 116 x 66 |
| Mounting | 2x M8 |
| Color | Black |
| Distance Between Holes | 80 mm |
| Actuation Angle | 73° |
| Port thread 21 | M16 x 1.5 JED - 388 |
| Port thread 1 | M16 x 1.5 JED - 388 |
| Exhaust | M16 x 1.5 JED-388 |
| Calculated Volume (dm³) | 1.3704 |
| Port thread 22 | M16 x 1.5 JED - 388 |
WABCO 9617231250 Cross References
| Brand | Part Number |
|---|---|
| 0034307481, 0034307381 | |
| DAF | 1519266 |
| MERCEDES-BENZ | 0034307381 |
