Name: WABCO 4630220200 Air Brake Control Valve - 3/2 Directional, 145.0 psi, M26 x 1.5 Mount
SKU: 4630220200
Price: 448.49 USD
Availability: InStock

WABCO part description

Directional Control Valve - 3/2

Product Attributes

Weight	0.39463
Max. operating pressure	145.0 psi
Calculated Volume (dm³)	0.25168
Size	119 x 47 x 45
Nominal Diameter	4.0 mm
Mounting	M26 x 1.5
Temperature Range	-40°C to +80°C
Actuation	Push
Port thread 3	Exhaust
Port thread 1	M10 x 1
Stroke	12.5 mm
Port thread 2	M10 x 1
Type	3/2
Actuating Range	12.5 mm
Exhaust	M12 x 1.5

WABCO 4630220200 Cross Reference

We have 18 alternatives for the 4630220200 by WABCO:

Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
