Carter Fuel Pumps P75006M - Fuel Pump Module Assembly
- Part Number
- P75006M
- Manufacturer
- CARTER FUEL PUMPS
- Description
-
Fuel Pump Module Assembly
details
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CARTER FUEL PUMPS part description
Product Description
Fuel Pump Module Assembly
Features & Benefits
- Carter Electric Fuel Pumps and Electric Fuel Pump Assemblies are made with all new materials under rigorous quality controlled manufacturing and testing procedures.
- Quality Carter Electric Fuel Pumps and Fuel Pump Assemblies deliver optimum performance while providing long life.
- Most applications include the necessary accessories such as tank seals, patented high-gradient density strainers and wiring harnesses.
- Fuel sensor design provides resistance to corrosive fuel blends and additives.
Product Attributes
| Fuel Sending Unit Included | Yes |
| Negative Ground | Yes |
| Outlet Outside Diameter | 9.49 MM |
| Voltage | 12 2H |
| Wiring Harness Length | 445.0 MM |
| Connector Color | White |
| Regulator Included | No |
| Terminal Type | Blade |
| Mounting Hardware Included | No |
| Height | 372 MM |
| Universal Or Specific Fit | Specific |
| Wire Quantity | 4 |
| Grade Type | Regular |
| Connector Shape | Oval |
| Gasket Or Seal Included | Yes |
| Housing Material | POM |
| Terminal Quantity | 4 |
| Top Mount Diameter | 113.0 MM |
| Lock Ring Included | No |
| Connector Gender | Female |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Inlet Quantity | 1 |
| Outlet Quantity | 1 |
| Fuel Filter Included | No |
| Resistance Ohms Empty | 40.0 82 |
| Resistance Ohms Full | 250.0 82 |
| Minimum Pressure | 60.0 PS |
| Internal Or External Strainer | External |
| Wire Harness Included | Yes |
| Outlet Fitting Thread Size | 5/16 IN |
| Fuel Tank Pressure Sensor Included | Yes |
| Minimum Flow Rating | 20 GPH |
| Pump Type | Electric |
| 65000 | No Proposition 65 warning is required with this product. |
Additional Information
| Country of Origin (Primary) | MX |
| EAR99 | |
| Harmonized Tariff Code (HTS) | 8413309030 |
| Warranty Special | Limited Lifetime Warranty |
| Warranty Special UOM | TX |
| UPC | 00614046681361 |
| VMRS Code | 044003258 |
| UNSPSC | 40151532 |
Part Interchanges
- E3952M
- General Motors 25344814
- 19177238
- 25178445
- 25178730
- 25320521
- 25344814
- 2630304
- 2920035
- 530-2220
- 67420
- 953-0016
- A27002
- AFS0437S
- C0353M
- F2963A
- FG0070
- M312880
- MPA27002
- P7002M
- RE0437S
- SP446M
- USEP3952M
- General Motors 25178445
- General Motors 25178730
- General Motors 25320521
- Dorman 2630304
- 1-800-Radiator 2920035
- GMB 530-2220
- Bosch Fuel Pumps 67420
- DENSO 953-0016
- Precision Fuel A27002
- EVO Driveline AFS0437S
- NAPA Fuel Pumps C0353M
- Purolator E3952M
- CARQUEST Fuel Pumps E3952M
- Facet E3952M
- Airtex Fuel Pumps E3952M
- Autobest F2963A
- Delphi Fuel Pumps FG0070
- Carquest Premium Fuel Pumps M312880
- MasterPro Fuel Pumps MPA27002
- NAPA Proformer P7002M
- EVO Driveline RE0437S
- Spectra Premium SP446M
- US Motor Works USEP3952M
- Canadian Tire 237984
- Precise 402-P3952M
- TYC 150012
- TI Automotive TU402
- TruGrade B11111440TG
- Sparta PN3002
- Carter Fuel Pumps P74760M
Fits Vehicles
- GMC Sonoma (1997-2002)
- Chevrolet S10 (1997-2002)
- Isuzu Hombre (1997-2000)
