(888) 312-8812 Login SignupCENTRIC 128.34106 Centric Premium OE Style Drilled Brake Rotor
Tap to view 4 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 128.34106 Part Description
Manufacturer
Product Description
Centric Premium OE Style Drilled Brake Rotor
Features & Benefits
- Premium rotors feature 100% fully machined finishes including rotor hats. This extra process provides better rotor balance and creates a cleaner; more finished looking component
CENTRIC 128.34106 Specifications
Product Attributes
| Weight [cntrc] Lbs | 23.200 |
| Product Grade [cntrc] | Premium |
| Vane Style [cntrc] | Curved |
| Disc Mounting [cntrc] | Floating |
| Misc Holes [cntrc] | 5 |
| Weight [cntrc] Kgs | 10.550 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Discard Thickness | 1.118 IN |
| Discard Thickness | 28.400 MM |
| Nominal Thickness | 29.800 MM |
| Nominal Thickness | 1.173 IN |
| Hat Finish | Coated |
| Overall Height | 62.500 MM |
| Overall Height | 2.461 IN |
| Outside Diameter | 360.000 MM |
| Outside Diameter | 14.173 IN |
| ABS Tone Ring Included | No |
| Surface Type | X Drilled |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 3.110 IN |
| Center Hole Diameter | 79.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.724 IN |
| Mounting Bolt Hole Circle Diameter | 120.000 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 14.500 MM |
| Stud/Lug Hole Diameter | 0.571 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | DE |
| UPC | 805890655992 |
CENTRIC 128.34106 Cross References
| Brand | Part Number |
|---|---|
| N/A | BD180294, 45552, 92031087D, 228.34106, 34112283385, 34112283801 |
| WAGNER | BD180294 |
CENTRIC 128.34106 Fits Vehicles
- BMW 1 Series M (2011)
- BMW M3 (2008-2013)
