Centric 125.63064 - Centric Premium High Carbon Alloy Brake Rotor
$12499
MSRP: $175.67
Save: $50.68
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric Premium High Carbon Alloy Brake Rotor
Features & Benefits
- Centric Premium Rotor with advanced metallurgy that greatly reduces pad squeal. Especially effective with higher friction; European style brake pad compounds. Added Molybdenum and Chromium to resist rotor cracking
Product Attributes
| Weight [cntrc] Lbs | 23.250 |
| Disc Mounting [cntrc] | Floating / DIH |
| Product Grade [cntrc] | Premium |
| Max Pb Drum Dia [cntrc] In | 7.264 |
| Vane Style [cntrc] | Pillar |
| Misc Holes [cntrc] | 0 |
| Max Pb Drum Dia [cntrc] Mm | 184.500 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 10.570 |
| Discard Thickness | 1.024 IN |
| Discard Thickness | 26.000 MM |
| Nominal Thickness | 28.000 MM |
| Nominal Thickness | 1.102 IN |
| Hat Finish | Coated |
| Overall Height | 2.693 IN |
| Overall Height | 68.400 MM |
| Outside Diameter | 350.000 MM |
| Outside Diameter | 13.780 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 184.000 MM |
| Nominal Drum Diameter | 7.244 IN |
| Bearings Included | No |
| Center Hole Diameter | 2.858 IN |
| Center Hole Diameter | 72.600 MM |
| Mounting Bolt Hole Circle Diameter | 4.528 IN |
| Mounting Bolt Hole Circle Diameter | 115.000 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.657 IN |
| Stud/Lug Hole Diameter | 16.700 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890703747 |
Part Interchanges
CENTRIC 125.63064 Cross Reference
We have 3 alternatives for the 125.63064 by CENTRIC:
Fits Vehicles
- Dodge Magnum (2006-2008)
- Dodge Charger (2006-2010, 2012-2022)
- Dodge Challenger (2008-2019, 2022)
- Chrysler 300 (2005-2010, 2012-2014, 2017-2019, 2023)
