CENTRIC part description

Product Description

Centric Premium Brake Rotor

Features & Benefits

  • Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life

Product Attributes

Vane Style [cntrc] Vented
Misc Holes [cntrc] 1
Hat Id [cntrc] In 5.870
Weight [cntrc] Lbs 18.800
Product Grade [cntrc] Premium
Disc Mounting [cntrc] Floating
California Proposition 65 Text [cntrc] WARNING: Cancer and Reproductive Harm
Hat Id [cntrc] Mm 149.100
Weight [cntrc] Kgs 8.520
Discard Thickness 23.000 MM
Discard Thickness 0.906 IN
Nominal Thickness 26.000 MM
Nominal Thickness 1.024 IN
Hat Finish Coated
Overall Height 45.600 MM
Overall Height 1.795 IN
Outside Diameter 300.000 MM
Outside Diameter 11.811 IN
ABS Tone Ring Included No
Surface Type Smooth
Solid Or Vented Type Rotor Vented
Bearings Included No
Center Hole Diameter 70.800 MM
Center Hole Diameter 2.787 IN
Mounting Bolt Hole Circle Diameter 115.000 MM
Mounting Bolt Hole Circle Diameter 4.528 IN
Stud/Lug Hole Quantity 5
Stud/Lug Hole Diameter 14.200 MM
Stud/Lug Hole Diameter 0.559 IN

Additional Information

Harmonized Tariff Code (Schedule B) 8708300050
NAFTA Preference Criterion Code B
Country of Origin (Primary) CN
Harmonized Tariff Code (HTS) 8708305030
UPC 805890728726

Part Interchanges

Fits Vehicles

  • Buick Envista (2024)
  • GMC Terrain (2018-2022)
  • Chevrolet Cruze (2014-2015)
  • Buick LaCrosse (2017-2019)
  • Buick Regal Sportback (2018-2020)
  • Chevrolet Trailblazer (2021-2022)
  • Buick Verano (2012-2017)
  • Buick Encore GX (2020-2024)
  • Chevrolet Malibu (2016-2023)
  • Chevrolet Equinox (2018-2019, 2021-2023)
  • Chevrolet Orlando (2012-2014)
  • Chevrolet Volt (2011-2015)
