CENTRIC part description

Product Description

C-Tek Standard Brake Rotor

Features & Benefits

  • Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket

Product Attributes

Disc Mounting [cntrc] Floating
Misc Holes [cntrc] 2
Weight [cntrc] Lbs 17.850
Product Grade [cntrc] Standard
California Proposition 65 Text [cntrc] WARNING: Cancer and Reproductive Harm
Weight [cntrc] Kgs 8.110
Discard Thickness 1.024 IN
Discard Thickness 26.000 MM
Nominal Thickness 28.000 MM
Nominal Thickness 1.102 IN
Overall Height 1.102 IN
Overall Height 28.000 MM
Outside Diameter 304.900 MM
Outside Diameter 12.004 IN
ABS Tone Ring Included No
Surface Type Smooth
Solid Or Vented Type Rotor Vented
Bearings Included No
Center Hole Diameter 2.598 IN
Center Hole Diameter 66.000 MM
Mounting Bolt Hole Circle Diameter 108.000 MM
Mounting Bolt Hole Circle Diameter 4.252 IN
Stud/Lug Hole Quantity 4
Stud/Lug Hole Diameter 0.512 IN
Stud/Lug Hole Diameter 13.000 MM

Additional Information

Harmonized Tariff Code (HTS) 8708305030
Harmonized Tariff Code (Schedule B) 8708300050
NAFTA Preference Criterion Code B
Country of Origin (Primary) CN
UPC 805890661450

Part Interchanges

Fits Vehicles

  • Peugeot 406 (2001-2002)
