Name: Centric 122.61051 Centric Premium Brake Drum
SKU: 12261051
Price: 50.49 USD
Availability: InStock

CENTRIC part description

Product Description

Centric Premium Brake Drum

Features & Benefits

OE style castings ensure superior performance and extended service life. Machined finishes provide cleaner appearance through wheels. Precision machined friction surfaces ensure smooth operation and reduced noise

Product Attributes

Misc Holes [cntrc]	3
Weight [cntrc] Kgs	4.318
Weight [cntrc] Lbs	9.500
Mounting Type [cntrc]	Floating
Bolt Circle Diameter [cntrc] Mm	107.950
Bolt Circle Diameter [cntrc] In	4.250
Hub Hole / Register [cntrc] Mm	63.500
Hub Hole / Register [cntrc] In	2.500
Height [cntrc] Mm	51.587
Height [cntrc] In	2.031
Friction Surface Width [cntrc] Mm	39.900
Friction Surface Width [cntrc] In	1.571
Product Grade [cntrc]	Premium
Maximum Brake Diameter (Discard)	201.500 MM
Maximum Brake Diameter (Discard)	7.933 IN
Bolt Hole Quantity	4
Outside Diameter	244.300 MM
Outside Diameter	9.618 IN
Outer Cooling Fins	No
Mounting Hole Diameter	14.000 MM
Mounting Hole Diameter	0.551 IN
Nominal Drum Diameter	200.000 MM
Nominal Drum Diameter	7.874 IN

Additional Information

Harmonized Tariff Code (Schedule B)	8708300050
NAFTA Preference Criterion Code	B
Country of Origin (Primary)	CN
Harmonized Tariff Code (HTS)	8708305030
UPC	805890665632

Part Interchanges

CENTRIC 122.61051 Cross Reference

We have 1 alternatives for the 122.61051 by CENTRIC:

RAYBESTOS 97811R

Fits Vehicles

Ford Fiesta (2011-2019)
