CENTRIC 121.46046 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
CENTRIC 121.46046 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating / DIH |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Max Pb Drum Dia [cntrc] Mm | 168.000 |
| Weight [cntrc] Kgs | 6.360 |
| Vane Style [cntrc] | Straight |
| Misc Holes [cntrc] | 3 |
| Max Pb Drum Dia [cntrc] In | 6.614 |
| Weight [cntrc] Lbs | 14.000 |
| Product Grade [cntrc] | Standard |
| Discard Thickness | 0.724 IN |
| Discard Thickness | 18.400 MM |
| Nominal Thickness | 20.000 MM |
| Nominal Thickness | 0.787 IN |
| Overall Height | 65.500 MM |
| Overall Height | 2.579 IN |
| Outside Diameter | 284.000 MM |
| Outside Diameter | 11.181 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 167.000 MM |
| Nominal Drum Diameter | 6.575 IN |
| Bearings Included | No |
| Center Hole Diameter | 90.000 MM |
| Center Hole Diameter | 3.543 IN |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.492 IN |
| Stud/Lug Hole Diameter | 12.500 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 805890647201 |
CENTRIC 121.46046 Cross References
CENTRIC 121.46046 Fits Vehicles
- Mitsubishi Diamante (1993-1995)
