CENTRIC part description

Product Description

C-Tek Standard Brake Rotor

Features & Benefits

  • Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket

Product Attributes

Disc Mounting [cntrc] Floating
Misc Holes [cntrc] 1
Weight [cntrc] Lbs 9.100
Weight [cntrc] Kgs 4.140
Product Grade [cntrc] Standard
California Proposition 65 Text [cntrc] WARNING: Cancer and Reproductive Harm
Discard Thickness 0.630 IN
Discard Thickness 16.000 MM
Nominal Thickness 17.900 MM
Nominal Thickness 0.705 IN
Overall Height 33.700 MM
Overall Height 1.327 IN
Outside Diameter 255.700 MM
Outside Diameter 10.067 IN
ABS Tone Ring Included No
Surface Type Smooth
Solid Or Vented Type Rotor Vented
Bearings Included No
Center Hole Diameter 2.559 IN
Center Hole Diameter 65.000 MM
Mounting Bolt Hole Circle Diameter 3.937 IN
Mounting Bolt Hole Circle Diameter 100.000 MM
Stud/Lug Hole Quantity 4
Stud/Lug Hole Diameter 0.543 IN
Stud/Lug Hole Diameter 13.800 MM

Additional Information

Harmonized Tariff Code (HTS) 8708305030
Harmonized Tariff Code (Schedule B) 8708300050
NAFTA Preference Criterion Code B
Country of Origin (Primary) CN
UPC 805890714026

Part Interchanges

Fits Vehicles

  • Volkswagen Gol Sedan (2010-2013)
  • Volkswagen Gol (2009-2013, 2016-2019)
  • Volkswagen Saveiro (2010-2017)
