SEALED POWER part description

Product Description

Engine Connecting Rod Bearing Set

Features & Benefits

  • Steel-backed bronze alloy lining with overplate
  • Popular for fatigue resistance & strength
  • Provides conformability required for older apps
  • Our standard material is comparable to competitors performance bearing
  • Note - This material offers less resistance to wear & corrosion than other materials.
  • Utilizes ISO & QS certified manufacturing

Product Attributes

Design Feature 1 Standard Size
Housing Bore Max (inch) 2.0871 IN
Housing Bore Max (mm) 53.0120 MM
Housing Bore Min (inch) 2.0866 IN
Housing Bore Min (mm) 53.0000 MM
Oil Clearance Max (inch) 0.0014 IN
Oil Clearance Max (mm) 0.0360 MM
Oil Clearance Min (inch) 0.0004 IN
Oil Clearance Min (mm) 0.0100 MM
Overall Length Max (inch) 0.7870 IN
Overall Length Max (mm) 19.9900 MM
Pair / Full / Half - Flange P
Part Description Engine Connecting Rod Bearing Set
Standard Shaft Max (inch) 1.9675 IN
Standard Shaft Max (mm) 49.9750 MM
Standard Shaft Min (inch) 1.9668 IN
Standard Shaft Min (mm) 49.9570 MM
Wall Thickness Max (inch) 0.0594 IN
Wall Thickness Max (mm) 1.5090 MM
Grade Type Premium

Additional Information

Country of Origin (Primary) MX
Canadian Harmonizing Tariff Code 8483300022
Harmonized Tariff Code (Schedule B) 8483308090
Harmonized Tariff Code (HTS) 8483308090
UPC 00614046036420

Part Interchanges

Fits Vehicles

  • Nissan Stanza (1990-1992)
  • Nissan Pickup (1995-1997)
  • Nissan D21 (1990-1994)
  • Nissan Altima (1993-2001)
  • Nissan 240SX (1989-1998)
  • Nissan Xterra (2000-2004)
  • Nissan Frontier (1998-2004)
  • Nissan Axxess (1990-1995)
