NGK Spark Plugs 2923 - NGK Standard Spark Plug
- Part Number
- 2923
- Manufacturer
- NGK SPARK PLUGS
- Description
-
NGK Standard Spark Plug
details
$242
MSRP: $3.52
Save: $1.10
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
NGK SPARK PLUGS part description
DR8ES-L S-PLUGS
Product Description
NGK Standard Spark Plug
Features & Benefits
- ACTUAL OE or EQUIVALENT DESIGN: OEM quality construction nickel alloy center electrode provides consistent performance
- RECOMMENDED USAGE: Best for vehicles with OE nickel alloy plugs, not recommended on vehicles with factory precious metal plugs
- NGK's OE CERAMIC TECHNOLOGY: High grade alumina silicate ceramic creates a stronger insulator for optimal dielectric performance
- SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
- COLD-ROLLED THREADS: Prevents cross-threading and damage to cylinder heads
- TRIVALENT METAL PLATING: Delivers superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal
Product Attributes
| Stock Number | 2923 |
| Part Number | DR8ES-L |
| Resistance | 5000.0 82 |
| Ground Electrode Tip Design | Standard |
| Ground Configuration | J-Gap |
| Ground Electrode Core Material | Nickel |
| Electrical Terminal Type | Stud |
| Center Electrode Core Material | Copper |
| Center Electrode Tip Material | Nickel |
| Pre-Gap Size | .028 IN |
| Ground Electrode Quantity | 1 |
| Hex Size | 18 MM |
| Insulator Height | 50.50 MM |
| Manufacturer Heat Range | 8 |
| Seat Type | Flat |
| Reach | 0.750 IN |
| Thread Diameter | 12.00 MM |
| Short Style Spark Plug | No |
| Service Number | DR8ES-L |
| Washer Included | Yes |
| Grade Type | Regular |
| Hex Size | 18mm |
| Insulator Height | 1.99 IN |
| Thread Diameter | 0.472 IN |
| Insulator Material | Ceramic |
| Resistor Type | Yes |
| 6648 | 0.0 IN |
| Ground Electrode Tip Material | Nickel |
| 9459 | No |
| 9506 | 0.06 IN |
| 9608 | Standard |
| 9745 | Crush |
| 9805 | Non-Projected |
Additional Information
| Warranty Time UOM | MO |
| Warranty Time | 2 |
| Country of Origin (Primary) | JP |
| Harmonized Tariff Code (HTS) | 8511100000 |
| UPC | 00087295129234 |
| VMRS Code | 033003005 |
| UNSPSC | 26101732 |
Part Interchanges
Fits Vehicles
- Ducati 750 Paso (1987)
- Honda TRX300EX Sportrax (1993-2008)
- Honda TRX200D FourTrax Type II (1991-1997)
- Honda TRX200 FourTrax (1990-1991)
- Honda NX125 (1988-1990)
- Honda TRX350D (1987-1989)
- Honda TRX250X (1987-1988, 1991-1992)
- Suzuki LT250EF (1986)
- Suzuki GV700GL Madura (1986)
- Honda TRX350 (1986-1987)
- Honda TRX200SX (1986-1988)
- Honda TR200 (1986-1987)
- Honda TLR200 (1986-1987)
- Suzuki GV1200 Madura (1985-1986)
- Honda TRX250 (1985-1987)
- Honda TRX125 (1985-1988)
- Honda ATC350X (1985-1986)
- Honda ATC250SX (1985-1987)
- Honda ATC250ES Big Red (1985-1987)
- Honda TRX200 (1984)
- Honda ATC200S (1984-1986)
- Honda ATC200M (1984-1985)
- Honda ATC200ES (1984)
- Honda ATC125M (1984-1987)
- Honda XL200R (1983-1984)
- Honda ATC200X (1983-1987)
- Honda XR500R (1982)
- Honda XR250R (1982)
- Honda XR200 (1982-1984)
- Honda XL500R (1982)
- Honda XL250R (1982-1983)
- Honda XL185S (1982-1983)
- Honda XL125S (1982-1985)
- Honda GL500I Silver Wing Interstate (1982)
- Honda GL500 Silver Wing (1982)
- Honda FT500 Ascot (1982-1983)
- Honda CX500C Custom (1982)
- Honda CT110 (1982-1986)
- Honda CM450E (1982)
- Honda CM450C Custom (1982)
- Honda CM450A Hondamatic (1982)
- Honda CBX (1982)
- Honda CB750SC Nighthawk (1982-1983)
- Honda CB750K (1982)
- Honda CB750F Super Sport (1982)
- Honda CB750C Custom (1982)
- Honda CB650SC Nighthawk (1982)
- Honda CB450T Hawk (1982)
- Honda CB450SC Nighthawk (1982)
- Honda CB125S (1982-1985)
- Honda ATC200E (1982-1983)
- Honda ATC200 (1982-1983)
- Honda ATC185S (1982-1983)
- Honda XR200R (1981-1983, 1986-2002)
- Honda GL1100 Gold Wing (1981)
- Honda CX500D Deluxe (1980-1981)
Headquartered in Wixom, Michigan, NGK® is a global leader in the design and manufacture of spark plugs for virtually every automotive and commercial vehicle application. It has grown immensely since its inception in 1936 with the expansion of its ignition product line and the introduction of its technical sensor and vehicle electronics line. NGK partners with OEMs and uses only the latest cutting tools to ensure each NGK product meets OE specifications for exact fit, form, and function. With world-class quality and engineering, NGK’s expertise goes beyond manufacturing the most reliable spark plugs for the automotive industry but also providing the best customer service possible.
