NGK Spark Plugs 7240 - NGK V-Power Spark Plug
- Part Number
- 7240
- Manufacturer
- NGK SPARK PLUGS
- Description
-
NGK V-Power Spark Plug
details
$288
MSRP: $3.31
Save: $0.43
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
NGK SPARK PLUGS part description
YR55 S-PLUGS
Product Description
NGK V-Power Spark Plug
Features & Benefits
- ACTUAL OE or EQUIVALENT DESIGN: OEM quality construction nickel alloy center electrode with V-groove provides consistent performance
- RECOMMENDED USAGE: Best for vehicles with OE nickel alloy plugs, not recommended on vehicles with factory precious metal plugs
- NGK's OE CERAMIC TECHNOLOGY: High grade alumina silicate ceramic creates a stronger insulator for optimal dielectric performance
- SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
- COLD-ROLLED THREADS: Prevents cross-threading and damage to cylinder heads
- TRIVALENT METAL PLATING: Delivers superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal
Product Attributes
| Stock Number | 7240 |
| Part Number | YR55 |
| Resistance | 5000.0 82 |
| Ground Electrode Tip Design | Standard |
| Ground Configuration | J-Gap |
| Ground Electrode Core Material | Nickel |
| Electrical Terminal Type | Non-Removable Nut |
| Center Electrode Core Material | Copper |
| Center Electrode Tip Material | Nickel |
| Pre-Gap Size | .060 IN |
| Ground Electrode Quantity | 1 |
| Hex Size | 5/8 IN |
| Insulator Height | 55.00 MM |
| Manufacturer Heat Range | 5 |
| Seat Type | Tapered |
| Reach | 0.460 IN |
| Thread Diameter | 14.00 MM |
| Short Style Spark Plug | No |
| Service Number | YR55 |
| Washer Included | No |
| Grade Type | Regular |
| Hex Size | 5/8" (16mm) |
| Insulator Height | 2.19 IN |
| Thread Diameter | 0.551 IN |
| Insulator Material | Ceramic |
| Resistor Type | Yes |
| 6648 | 0.0 IN |
| Ground Electrode Tip Material | Nickel |
| 9459 | No |
| 9506 | 0.04 IN |
| 9608 | Standard |
| 9805 | Non-Projected |
Additional Information
| Harmonized Tariff Code (HTS) | 8511100000 |
| Warranty Time UOM | MO |
| Warranty Time | 2 |
| Country of Origin (Primary) | JP |
| UPC | 00087295172407 |
| VMRS Code | 033003005 |
| UNSPSC | 26101732 |
Part Interchanges
- Bosch 7573
- Bosch 7584
- Bosch 7973
- Bosch HR10ACY
- Bosch HR10AY
- Bosch HR8ACY
- Bosch HR8AY
- Bosch HR9ACY
- Bosch HR9AY
- Champion Spark Plug 108
- Champion Spark Plug 35
- Champion Spark Plug RV12C6
- Champion Spark Plug RV8C6
- Motorcraft ARF2-6
- Motorcraft ARF3-6
- Motorcraft ARF4-6
- Motorcraft ARF41C15
- Motorcraft ARF41CU15
- Motorcraft ARF8-6
- Autolite 3623
- Autolite 3625
- Autolite 3627
- Autolite 683
- Autolite 684
- Autolite 685
- Autolite 687
- NGK 7240
- ACDelco 1835738T
- ACDelco R42TX
- ACDelco R43T6
- ACDelco R43TX
- ACDelco R44TX
- ACDelco R45TX
- ACDelco R46TX
Fits Vehicles
- GMC G35/G3500 Van (1974)
- GMC G25/G2500 Van (1974)
- GMC G15/G1500 Van (1974)
- Chevrolet G30 Van (1974)
- Chevrolet G20 Van (1974)
- Chevrolet G10 Van (1974)
- Pontiac Ventura (1975)
- Pontiac LeMans (1975)
- Pontiac Grand LeMans (1975)
- Pontiac Firebird (1975)
- Oldsmobile Omega (1975)
- Oldsmobile Cutlass Supreme (1975)
- Oldsmobile Cutlass (1975)
- GMC Sprint (1975-1977)
- GMC P35 (1975, 1977-1978)
- GMC P25 (1975, 1977-1978)
- GMC P15 (1975)
- GMC K35 (1977-1978)
- GMC K25 Suburban (1975, 1977-1978)
- GMC K25 (1975, 1977-1978)
- GMC K15 Suburban (1975, 1977)
- GMC K15 (1975, 1977-1978)
- GMC Jimmy (1975, 1977-1978)
- GMC G35 (1975, 1977-1978)
- GMC G25 (1975, 1977-1978)
- GMC G15 (1975, 1977-1978)
- GMC Caballero (1978)
- GMC C35 (1975, 1977-1978)
- GMC C25 Suburban (1975, 1977-1978)
- GMC C25 (1975, 1977-1978)
- GMC C15 Suburban (1975, 1977-1978)
- GMC C15 (1975, 1977-1978)
- Chevrolet P30 (1975, 1977-1978)
- Chevrolet P20 (1975, 1977-1978)
- Chevrolet P10 (1975, 1977)
- Chevrolet Nova (1975)
- Chevrolet Monza (1975)
- Chevrolet Monte Carlo (1975)
- Chevrolet Malibu (1975)
- Chevrolet Laguna (1975)
- Chevrolet K30 (1977-1978)
- Chevrolet K20 Suburban (1975, 1977-1978)
- Chevrolet K20 (1975, 1977-1978)
- Chevrolet K10 Suburban (1975, 1977-1978)
- Chevrolet K10 (1975, 1977-1978)
- Chevrolet Impala (1975)
- Chevrolet G30 (1975-1978)
- Chevrolet G20 (1975-1978)
- Chevrolet G10 (1975-1978)
- Chevrolet El Camino (1975, 1978)
- Chevrolet Corvette (1975)
- Chevrolet Caprice (1975)
- Chevrolet Camaro (1975)
- Chevrolet C30 (1975, 1977-1978)
- Chevrolet C20 Suburban (1975, 1977-1978)
- Chevrolet C20 (1975, 1977-1978)
- Chevrolet C10 Suburban (1975, 1977-1978)
- Chevrolet C10 (1975, 1977-1978)
- Chevrolet K5 Blazer (1975, 1977-1978)
- Chevrolet Bel Air (1975)
- Buick Apollo (1975)
Headquartered in Wixom, Michigan, NGK® is a global leader in the design and manufacture of spark plugs for virtually every automotive and commercial vehicle application. It has grown immensely since its inception in 1936 with the expansion of its ignition product line and the introduction of its technical sensor and vehicle electronics line. NGK partners with OEMs and uses only the latest cutting tools to ensure each NGK product meets OE specifications for exact fit, form, and function. With world-class quality and engineering, NGK’s expertise goes beyond manufacturing the most reliable spark plugs for the automotive industry but also providing the best customer service possible.
