(888) 312-8812 Login SignupDONALDSON P551000 Fuel Water Separator Filter - 9.92 in., Water Separator Type, Spin-On Style, Composite Media Type, Not for Marine Applications
MSRP: $45.80
$2299
Save $22.81
Limited availability at this price!
In Stock
Get it by Tuesday, Jun 16
DONALDSON P551000 Part Description
Manufacturer
Product Description
FUEL FILTER, WATER SEPARATOR SPIN-ON TWIST&DRAIN
Features & Benefits
- 9.92 in. housing height creates an extended profile
- Composite media layers combine filtration and separation
- Spin-on style base simplifies mounting alignment
- Sealed outer shell provides a secure structural feel
Donaldson Fuel Filter Water Separator
The Donaldson Fuel Filter Water Separator conditions diesel fuel by separating moisture from the fuel stream before it reaches injection components. As fuel circulates through composite media, suspended water droplets are drawn together and isolated from the primary flow path, reducing the risk of corrosion and injector wear. This separation process operates continuously during engine use, supporting cleaner fuel delivery under variable load conditions. Configured as a spin-on style assembly and identified as a water separator type, it threads directly onto compatible mounting heads. It is not intended for marine applications. The Donaldson P551000 manages fuel and moisture separation within compatible diesel systems.
DONALDSON P551000 Specifications
Product Attributes
| Length | 9.92 in |
| Collapse Burst | 5.2 BAR |
| Efficiency 99% | 10 MICRON |
| Efficiency Test Std | SAE J1488, J1985 |
| Emulsified H2O Efficiency | 96 PERCENT |
| Gasket Id | 2.44 IN |
| Gasket Od | 2.83 IN |
| Media Type | Composite |
| Notes | Not for Marine Applications |
| Outer Diameter | 3.66 IN |
| Stand Pipe | Yes Y/N |
| Style | Spin-On |
| Thread Size | 1-14 UN |
| Type | Water Separator |
| Brand | Twist&Drain |
| Length | 9.92 IN |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (HTS) | 8421230000 |
| UPC | 00742330043578 |
DONALDSON P551000 Cross References
| Brand | Part Number |
|---|---|
| AC DELCO | TP1292 |
| AGCO | 72515622 |
| AMERICAN MOTORS CORPORATION | SFF1000 |
| AMERICAN PARTS | 95406 |
| ATLAS COPCO | 5541709800 |
| BALDWIN | BF1259 |
| FLEETGUARD | FS1000 |
| FRAM | PS8048 |
| LUBER-FINER | LFF1000 |
| MANN-HUMMEL FILTERS | WK 965/4 X |
| N/A | BF1249SP, FF1063, Z822, PS8048, PS6829, FS344, F71000, 12977622, 33406MP, 33406, 95431, 95406, BF1249, BF1259, 86406, YE3329289, YEFS1000, 40C0433, FF105HP, 11NB70010, 1SN626001, FSR81000, ABPN10GFS1000, 3406, EFF9090, J8620000, 170014406, 19500500, TP1292, 3161407, 3329289, 3843750, 3889716, 5001779, 10064607, 2568753, 3I2113, SFF1000, YN02PU1010P1, FC5709, 1273400213, WGFS1000, WGFS1242, SN40512, SN55001, DNP551000, 32925968, 170013418, 4377880, 43778801, E12977622, L4377880, X57536400006, WK965, WK965X, 97400033, 47400033, 72515622, 57479123, H181WK, RE160384, 1310368H2, 131036H2, BF2486, CU3329289, CUFS1000, 5614398, 1515707, 04FS1000, 15271319, 86029143, 29213450, 5541709800, 91756080, 84557707, J329289, 807201962, 4136470, 86021254, 86991015, L86991015, 85114046, FS1000, 2191P551000, GPP1000, FSW4140, 3381757H1, 1478371 |
| PREMIUM GUARD | DW30069 |
| PUROLATOR | F71000 |
| WIX FILTERS | 33406 |
DONALDSON P551000 Fits Vehicles
- International 9900i (2000-2002)
- Volvo VNL (2000-2002)
- Volvo VNM (2000-2002)
- Volvo FE (1998)
- Volvo VHD (2001-2002)
- Volvo WX (1996-2002)
- Volvo WH (1996)
- Volvo WAH (1996-2002)
- Volvo WC (1996-1998)
- Volvo ACL (1996-2002)
- Volvo WI (1996-1998)
- Volvo WG (1996-2001)
- Volvo VN (1998-1999)
- Western Star 6900XD (2002-2008, 2011-2012)
- Western Star 4900FA (2002-2017)
- Western Star 4900EX (2002-2009, 2011-2015)
- Western Star 4900SA (2002-2017)
- Peterbilt 389 (2008-2011)
- Kenworth C550 (1994)
- Peterbilt 388 (2008-2011)
- Peterbilt 386 (2006-2013)
- Peterbilt 367 (2008-2011, 2018)
- Kenworth T660 (2008-2013, 2018)
- Kenworth K100E (1994-2002, 2005-2006)
- Kenworth C500 (1981-2002, 2005-2015)
- Peterbilt 384 (2008-2012)
- Peterbilt 365 (2008-2011, 2013, 2016)
- Peterbilt 340 (2009-2010)
- Peterbilt 385 (1995-2007)
- Kenworth T400 (1993-1998)
- Peterbilt 320 (2003-2011)
- Peterbilt 335 (2009-2010)
- Kenworth W900 (2000-2013, 2016)
- Kenworth T800 (1987-2012)
- Peterbilt 387 (1981, 2000-2011)
- Kenworth T2000 (1997-2003, 2005-2009, 2011)
- Freightliner Coronado (2001, 2003-2009, 2013)
- Freightliner FL106 (2000)
- Freightliner Cascadia (2008-2010, 2012, 2014)
- Freightliner FL60 (2004)
- Freightliner Condor (2001-2007)
- Freightliner Columbia (2000-2010)
- Freightliner Classic XL (2001-2003)
- Freightliner Classic (2001-2011)
- Freightliner Argosy (1999-2006, 2008)
- Freightliner Century Class (1997-2009)
- Freightliner FL112 (1996-2004)
- International ProStar (2009-2010)
- International WorkStar 7700 (2008-2012)
- International WorkStar 7600 (2008-2014)
- International 7700 (2005-2007)
- International 7600 (2003-2007)
- International 9900i SFA (2000-2002)
- International 9200i SBA (2000-2011)
- International 5600i (2000-2012)
- International 5500i (2000-2012)
- International 5000 (1998-2000, 2002)
- International 2574 (1998-2003)
- International 9400 (1990-2000)
- International 2674 (1998-2003)
- International 2654 (1999-2000)
- International 2554 (1999-2000)
- Kenworth T300 (1996-2007)
- Freightliner FL50 (1995-2004)
