(888) 312-8812 Login SignupDONALDSON M090823 Exhaust Muffler - 48.00 in. Overall length
MSRP: $613.31
$58799
Save $25.32
Limited Availability
Due to limited availability, we will confirm your order and notify you within 1 business day.
DONALDSON M090823 Part Description
Manufacturer
Features & Benefits
- Controls noise levels, reducing engine roar while maintaining efficiency
- Helps regulate backpressure for better fuel economy and engine performance
- Works to direct harmful emissions away from the vehicle, improving safety
- Created for easy installation in extreme-duty applications
Donaldson Muffler Round Style 3
There are layers to what makes an exhaust system work efficiently, and the muffler plays a major role. The Donaldson Muffler Round Style 3 is created to control noise, manage backpressure, and help optimize engine efficiency. At 48 inches in length, it provides a strong balance of sound reduction and airflow management, helping to keep the engine performing smoothly. Moreover, this muffler is tough enough to last through the punishing environment of trucking and construction work. When it comes to keeping an engine breathing right, the Donaldson M090823 makes all the difference.
DONALDSON M090823 Specifications
Product Attributes
| Body Length | 44.31 in |
| Overall Length | 48.00 in |
| Attenuation Hr | 20 dBA |
| Attenuation Lr | 15 dBA |
| Back Pressure High-range | Hg2.99 inch Hg) |
| Back Pressure Low-range | Hg0.98 inch Hg) |
| Back Pressure Mid-range | Hg2.01 inch Hg) |
| Body Diameter Maximum | 9.00 in |
| Inlet Clock Position | 12/31/1899 6:00:00 AM |
| Inlet Diameter | 4.02 in |
| Outlet Diameter | 5.03 in |
| Rated Flow Hr | 65.9 m³/min (2327 cfm) |
| Rated Flow Lr | 38.1 m³/min (1345 cfm) |
| Rated Flow Mr | 53.8 m³/min (1900 cfm) |
| Style | Style 3 |
DONALDSON M090823 Cross References
DONALDSON M090823 Customer Reviews
No reviews yet
Be the first to review this product!
DONALDSON M090823 Manufacturer Information
For more than 100 years, Donaldson® has provided effective solutions to complex filtration challenges in various industries. Fleet managers worldwide have relied on Donaldson’s wide range of filtration products to ensure their trucks operate at peak efficiency and reduce expenses and maintenance downtime in the long run. These products include air intake filters and cleaners, cabin air filters, coolant filters, fuel filters and water separators, transmission filters, exhaust filtration products, and so much more. Each Donaldson filtration product is engineered for durability and performance that matches that of the original. Whether they are long-haul trucks, school buses, dump trucks, or other commercial vehicles, Donaldson filtration products will help keep them running smoothly.
