Dana 90-53-11 - Drive Shaft Midship Stub Shaft - For Use With End Yoke or Companion Flange
$15599
MSRP: $234.30
Save: $78.31
In stock
limited availability at this price!
. Learn more
DANA part description
| Brand: | Spicer |
| For Use With: | End Yoke Or Companion Flange |
| Series: | SPL90 |
| Material: | Steel |
| Spline O.D.: | 1.75 |
| Number of Splines: | 34 I |
| Involute: | Y |
| Fits Tube Diameter: | 4 |
| Fits Tube Wall: | 0.259 |
| Spline End to Brg Shoulder (Y): | 3.125 |
| Spline End to Weld (K) IN.: | 4.219 |
| Spline Length (L) IN.: | 2 |
| Thread Size: | 1.250-18 |
| Shoulder Diameter (B) IN.: | 2.188 |
| Shoulder Length (G) IN.: | 0.812 |
| Bearing Diameter (C) IN.: | 1.771 |
| VMRS: | 24002060 |
| Butt Diameter: | 3.743 |
| Style: | 2 |
| Bearing Diameter (Max): | 1.7717 |
| Bearing Diameter (Min): | 1.7712 |
| Package Type: | Each |
| Package Quantity: | 1 |
| Weight: | 5.64 lbs. |
| Country of Origin: | United States |
| UPC Code: | 023913215682 |
Features & Benefits
- Dana manufactured Spicer components are designed, engineered, tested, and manufactured to meet or exceed OE requirements.
- Spicer components are engineered to meet or exceeds the performance requirements of the original factory driveline component
- Tested for unparalleled reliability
- Strength and durability for long life
Product Attributes
| Series | SPL90 |
| Material | Steel |
| Thread Size | 1.250-18 IN |
| Style | 2 |
| Fits Tube Diameter | 4.000 IN |
| Number of splines | 34 I |
| Involute | Y |
| Fits Tube Wall | .259 IN |
| Butt Diameter | 3.743 IN |
| Bearing Diameter (C) In. | 1.771 IN |
| Bearing Diameter (Max) | 1.7717 IN |
| Spline End To Weld (K) In. | 4.219 IN |
| Spline Length (L) In. | 2.000 IN |
| Spline O.D. | 1.750 IN |
| Bearing Diameter (Min) | 1.7712 IN |
| For Use With | End Yoke Or Companion Flange |
| Shoulder Diameter (B) In. | 2.188 IN |
| Shoulder Length (G) In. | .812 IN |
| Spline End To Brg Shoulder (y) | 3.125 |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8482200000 |
| Harmonized Tariff Code (HTS) | 8482200000 |
| UPC | 00023913215682 |
| VMRS Code | 024002060 |
Part Interchanges
- Harman Kardon 90-53-11
- Neapco OE Series N5-53-271
- Daimler Truck North America SP 90 53 11
- Daimler Truck North America SP 90 53 11HP
- Dana Commercial Vehicle Service Parts 5-53-271
- Volvo SP 905311
- International Harvester (IHC) 905311
- International Harvester (IHC) D905311
- International Harvester (IHC) E905311
- Navistar 1681120C1
- Navistar 553271
- Navistar D553191
- Navistar D553271
- Navistar D905311
- Navistar DS905311
- Navistar E553191
- Navistar E553271
- Navistar ETN905311
- Freightliner SP 90 53 11
- Freightliner SP 90 53 11HP
- Neapco OE Series N5-53-191
- UAP 90-53-11
DANA 90-53-11 Cross Reference
We have 2 alternatives for the 90-53-11 by DANA:
