(888) 312-8812 Login SignupPETERSON LIGHTING 701C LED Headlight, Round, Par 56, 7", white, box
Tap to view 6 more
MSRP: $494.40
$17499
Save $319.41
Limited availability at this price!
In Stock
Get it by Monday, Feb 9
PETERSON LIGHTING 701C Part Description
Manufacturer
Product Description
LED HEADLIGHT, ROUND, PAR 56, 7"
Features & Benefits
- 7" Round PAR 56 Headlight
- Drop-in LED replacement for all PAR56 7-inch standard headlights.
- Multi-volt design is compatible with both 12V and 24V systems.
- DOT-legal; exceeds FMVSS-108 and CMVSS-108 requirements.
- Standard H4 3-blade terminals integrated into cast alloy rear housing.
- 1100 / 1650 lumen output (low / high beam).
- Draws only 0.7–1.9 amps.
- Draws only 0.7-1.9 amps.
- 5400 – 6400k color temperature closely matches natural daylight.
- 5400 - 6400k color temperature closely matches natural daylight.
- Certified to meet IP66 ingress protection rating.
- Heavy-duty polycarbonate lens and cast alloy housing.
- Does not function as a daytime running light (DRL).
- Requires 701-491 anti-flicker harness for use on CANBUS-equipped vehicles, including '07 and newer Jeep Wrangler.
- V701KC-2 Kit includes 2 headlights & two 701-491 anti-flicker harnesses.
- For left-hand traffic, see ECE version on Peterson's website.
anti-flicker harness - Viz Pack - 701-491 - std qty
701 Great White® LED 7" PAR 56 Round Headlight
Peterson Lighting Great White® LED 7" PAR 56 Round Headlight
The Peterson Lighting Great White® LED 7" PAR 56 round headlight is a cost-effective investment since it offers a longer service life than standard headlights. It is suitable for mounting on any truck, and it is made temperature-, weather-, and vibration-resistant to ensure a safer driving experience.
Features & Benefits
- Made with heavy-duty polycarbonate lens that is bonded to a rugged aluminum housing to form a single unit
- Designed to replace standard 7" incandescent sealed beam
- With superior light output but consumes low power as it draws only 17 to 22 watts
- Has standard H4 electrical connection with separate high beam (1650 lumens) and low beam (1100 lumens) functions
- Can be used on CANBUS-equipped vehicles, including '07 and newer Jeep Wrangler, but requires a 701-491 anti-flicker harness
- Not ECE-compliant but DOT-legal, exceeding FMVSS 108 and CMVSS 108 requirements and meeting applicable SAE standard
- Operating range is 9 to 32 volts with form factor that matches a standard 2D1 configuration
- Must not be used as a daytime running light (DRL)
- IP66 ingress-rated with its patent pending
PETERSON LIGHTING 701C Specifications
Product Attributes
| Average Current Draw | 1.66 68 |
| Brightness | 1650 LU |
| Brightness | 1650 LU |
| Bulb Technology | LED |
| Bulb/diode Count | 2 |
| California Prop65 Required | Y |
| Color Temperature | 5400 - 6400k |
| Container Type | box |
| Diameter | 7 IN |
| Height | 7 in |
| Length | 7 in |
| Lens Color | clear |
| Light Color | white |
| Maximum Amperage Draw | 1.992 68 |
| Maximum Voltage | 32 Volts |
| Minimum Voltage | 9 Volts |
| Multi-volt | Y |
| Regulatory Compliance | DOT |
| Shape | round |
| Termination | H4 |
| Voltage | 12V / 24V |
| Width | 3.9 in |
Additional Information
| Warranty Special | See full warranty terms: https://pmlights.com/warranty |
| Warranty Special UOM | TX |
| Warranty Time | 3 |
| Warranty Time UOM | YR |
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8512202000 |
| UPC | 00044464992747 |
| VMRS Code | 034001151 |
PETERSON LIGHTING 701C Cross References
PETERSON LIGHTING 701C Customer Reviews
No reviews yet
Be the first to review this product!
PETERSON LIGHTING 701C Manufacturer Information
Peterson Lighting® is a family-owned company that produces and distributes vehicle safety lighting systems mirrors, and other related safety products and accessories. It has been in the business for 75 years, and currently, it offers over 2,200 products designed for various applications, including tilt-bed and cargo vehicles and light- and medium-duty trailers. Peterson Lighting believes that full commitment to quality is its responsibility as a market leader. All its components are designed and manufactured only in its ISO 9001/QS-9000-certified facility in Grandview, MO. This facility is handled by knowledgeable and highly skilled specialists, who are as dedicated and passionate as the company when it comes to quality.
