MOOG part description

  • Specifications

    BALL BEARING: Part Description: Ball Bearing
    Inner Race Bore (Inch): 1.181
    Inner Race Bore (MM): 30.000
    Inner Race Width (Inch): 0.630
    Inner Race Width (MM): 16.000
    Inner Race Radius (Inch): 0.040
    Inner Race Radius (MM): 1.020
    Outer Race Outside Diameter (Inch): 2.441
    Outer Race Outside Diameter (MM): 62.000
    Outer Race Width (Inch): 0.630
    Outer Race Width (MM): 16.000
    Outer Race Radius (Inch): 0.040
    Outer Race Radius (MM): 1.020
    Bore (Inch): 1.181
    Bore (MM): 30.000
    Outside Diameter (Inch): 2.441
    Outside Diameter (MM): 62.000
    Width (Inch): 0.630
    Width (MM): 16.000
    Series: 1200
    Design: Single Row Radial
    Type: B-1

Product Description

Ball Bearing

Application Summary

AMC; Chrysler; Fuller; H/D Truck; New Process; Spicer (Misc)

Features & Benefits

  • BUILT TO LAST -- Advanced heat treatment process for strength
  • PREMIUM MATERIALS -- Precision manufactured using premium-grade steel for lasting performance and extended bearing life
  • RELIABLE PERFORMANCE -- Element size and quantity are engineered to meet or exceed the load rating of OE bearings
  • COMPREHENSIVE COVERAGE -- Industry-leading coverage for domestic and import applications
  • RIGOROUS TESTING?--?Comprehensive?testing throughout design and development processes by National engineers for quality you can count on

Product Attributes

Bore (inch) 1.181 IN
Bore (mm) 30.000 MM
Design Single Row Radial
Inner Race Bore (inch) 1.181 IN
Inner Race Bore (mm) 30.000 MM
Inner Race Radius (inch) 0.040 IN
Inner Race Radius (mm) 1.020 MM
Inner Race Width (inch) 0.630 IN
Inner Race Width (mm) 16.000 MM
Outer Race Outside Diameter (inch) 2.441 IN
Outer Race Outside Diameter (mm) 62.000 MM
Outer Race Radius (inch) 0.040 IN
Outer Race Radius (mm) 1.020 MM
Outer Race Width (inch) 0.630 IN
Outer Race Width (mm) 16.000 MM
Outside Diameter (inch) 2.441 IN
Outside Diameter (mm) 62.000 MM
Part Description Ball Bearing
Series 1200
Type B-1
Width (inch) 0.630 IN
Width (mm) 16.000 MM

Additional Information

Country of Origin (Primary) DE
Harmonized Tariff Code (Schedule B) 8482105032
Harmonized Tariff Code (HTS) 8482105032
UPC 00724956044399

Part Interchanges

For over 100 years, Moog® has been an industry leader in mid- to high-end aftermarket parts for steering, suspension, and driveline systems worldwide. Utilized by daily commuters to entire fleets, Moog parts have become synonymous with reliable performance that’s just as good or even better than their OE counterparts. Moog also incorporates innovative features in their products not found in competing products, such as patented forged steel bodies and metal “gusher” bearings that greatly reduce friction across moving components. The brand also leads the way in after-sales support, with comprehensive technical assistance and training materials available for customers around the world.
