(888) 312-8812 Login SignupDANA 6-4-4271 1710 Series Power Take Off (PTO) End Yoke - Steel, 4.750 C/L To End Hub S, BP Yoke Style
Tap to view 1 more
MSRP: $439.31
$38449
Save $54.82
Limited availability at this price!
In Stock
Get it by Thursday, Jan 8
DANA 6-4-4271 Part Description
Manufacturer
Features & Benefits
- Genuine OE quality. Tested and proven.
- Built to meet OE standards set by Dana.
- Tested and validated to rigorous OE specifications.
- Latest production upgrades ensure genuine Spicer parts are as good or better than the OE parts they replace.
End yoke - Series 336
Special Note: Lead Time30 Days
DANA 6-4-4271 Specifications
Product Attributes
| Series | 1710 |
| Material | Steel |
| Spline Count | 16 |
| Type | Splined Hole |
| Hub Diameter R | 2.375 IN |
| Involute Spline | I |
| Length Thru Hole Q | 2.000 IN |
| Outside Yoke Dimension (In) E | 6.094 IN |
| Yoke Bearing Dimension (In) D | 1.938 IN |
| Yoke Style | BP |
| Major Diameter | 1.775 IN |
| C/L To End Hub S | 4.750 IN |
| C-Bore Depth | 0.190 IN |
| C-Bore Diameter | 1.810 IN |
| Joint Angle #1 | 34 |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 8708990000 |
| Harmonized Tariff Code (HTS) | 8708990000 |
| UPC | 00023913223243 |
| VMRS Code | 056002014 |
DANA 6-4-4271 Part Interchanges
| Brand | Part Number |
|---|---|
| Clarke | 119756 |
| Daimler Truck North America | SP 6 4 4271, SP 6 4 4271HP |
| Dana Commercial Vehicle Service Parts | 2104-644271 |
| Volvo | 2104-644271, SP 644271 |
| International Harvester (IHC) | 644271, D644271, E644271 |
| Navistar | 644271, D644271, DS644271, E644271 |
| Paccar Parts | 6/4/4271 |
| Mack | 2104-644271 |
| Freightliner | SP 6 4 4271, SP 6 4 4271HP |
