Name: Dana 6-4-2501-1 1710 Series Drive Shaft End Yoke - Steel, 10 Spline, HR Yoke Style, Splined Hole
SKU: 6425011
Price: 343.2 USD
Availability: OutOfStock

DANA part description

End yoke - Series 7497

Special Note: Lead Time30 Days

Features & Benefits

Uses high-grade Dana approved materials to ensure optimal quality.
Dana designed, tested and engineered.
Genuine OE quality. Tested and proven.

Product Attributes

Series	1710
Material	Steel
Spline Count	10
Type	Splined Hole
Hub Diameter R	3.250 IN
Involute Spline	N
Length Thru Hole Q	3.000 IN
Outside Yoke Dimension (In) E	6.190 IN
Yoke Bearing Dimension (In) D	1.938 IN
Yoke Style	HR
Major Diameter	2.250 IN
C/L To End Hub S	5.250 IN
C-Bore Depth	0.250 IN
C-Bore Diameter	2.3 IN

Additional Information

Country of Origin (Primary)	US
Harmonized Tariff Code (Schedule B)	8708990000
Harmonized Tariff Code (HTS)	8708990000
UPC	00023913296629
VMRS Code	024001003

Part Interchanges
