(888) 312-8812 Login SignupDANA 6-2-789 1710 Series Drive Shaft Flange Yoke - Steel, 8 Bolt Holes, Circular Design
Tap to view 1 more
$43649
Limited availability at this price!
In Stock
Get it by Thursday, Feb 12
DANA 6-2-789 Part Description
DANA 6-2-789 Specifications
Product Attributes
| Series | 1710 |
| Material | Steel |
| Number of Bolt Holes | 8 |
| Design | Circular |
| Bolt Circle Dia. In. (B) | 7.250 IN |
| Bolt Hole Dia. In (B) | .375 - DRILLED IN |
| Flange Face To C/L In. (G) | 3.000 IN |
| Flange Or Swing Dia. In. (A) | 8.000 IN |
| Outside Yoke Dimension In.(E) | 6.094 IN |
| Pilot Dia. M=male F=female (c) | 6.438 - MALE |
| Yoke Bearing Dimension In. (D) | 1.938 IN |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8708990000 |
| Harmonized Tariff Code (HTS) | 8708990000 |
| UPC | 00023913223007 |
| VMRS Code | 024002016 |
DANA 6-2-789 Cross References
| Brand | Part Number |
|---|---|
| Allison Transmission | 02377975, 29500566 |
| Blue Bird | 0003423 |
| Daimler Truck North America | SP 6 2 789, SP 6 2 789HP |
| Dana Commercial Vehicle Service Parts | 2104-62789 |
| Emergency One | 285405 |
| Euclid | E4067876 |
| Freightliner | SP 6 2 789, SP 6 2 789HP |
| General Motors | 2377975, 29500566 |
| International Harvester (IHC) | 62789, 9870099R1, 987099R1, D62789, E62789 |
| Lodal | 9940194 |
| Mack | 2104-62789 |
| Navistar | 62789, 9870099R1, 987099R1, D62789, DS62789, E62789 |
| Paccar Parts | 6-2-789 |
| Peterbilt | 17DS225 |
| Rockwell International | 17N6X |
| Terex | 2377975 |
| UAP | 6-2-789 |
| VME | E4067876 |
| Volvo | 2104-62789, E4067876, SP 62789 |
DANA 6-2-789 Customer Reviews
No reviews yet
Be the first to review this product!
DANA 6-2-789 Manufacturer Information
Dana Holding Corporation® is an internationally known company specializing in drivetrain and e-Propulsion systems. It conceptualizes, manufactures, and supplies energy-management and power- and conveyance solutions for the present-day and future vehicles and trucks. With its over 115 years of industry experience and innovation, and despite several turbulences the automotive and trucking industry has been through, Dana has managed to take the lead in revolutionary technological inventions. Dana Holding Corporation comprises different world-renowned brands catering to various market segments. These include SPICER Drivetrain Systems, VICTOR REINZ Sealing Products, LONG Thermal Products, BREVINI Motion Systems, GRAZIANO High-Performance Transmissions, FAIRFIELD Custom Gears and Drives, and a lot more.
