Dana 6.5-4-3851-1X - 1810 Series Differential End Yoke - Assembly, Steel, HR Yoke Style, 39 Spline

Part Number
6.5-4-3851-1X
Manufacturer
DANA
Description

1810 Series Differential End Yoke - Assembly, Steel, HR Yoke Style, 39 Spline

details

$448.49

MSRP: $529.25

Save: $80.76

In stock

limited availability at this price!

New! No hassle Return Policy details
Free Economy shipping on orders over $299 details
Orders placed over the weekend will ship the following business day
Get it by Thursday, Dec 26
Pay over 3-12 months with Affirm Logo. Learn more
Minus Plus

DANA part description

Spicer 6.5-4-3851-1X End Yoke 2.024"X39Spl
6.5438511X
PLEASE USE THE DANA ONILNE END YOKE CATALOG TO SELECT YOUR PART NUMBERS

6.5-4-3851-1X
JOINT SERIES:1810
D DIMENSION:1.94
E DIMENSION:7.55
YOKE STYLE:Half Round
Q LENGTH THRU HOLE:2.32
R HUB DIAMETER:3
S CENTERLINE TO END:5.188
SPLINE COUNT:39
SPLINE OD:2.024
NOTES:

Product Attributes

Series 1810
Material Steel
Spline Count 39
Type Splined Hole
Assembly Y
Hub Diameter R 3.000 IN
Includes Slinger/Plug Y
Involute Spline N
Length Thru Hole Q 2.320 IN
Outside Yoke Dimension (In) E 7.643 IN
Yoke Bearing Dimension (In) D 1.938 IN
Yoke Style HR
Major Diameter 2.024 IN
C/L To End Hub S 5.188 IN
C-Bore Depth 0.900 IN

Additional Information

Country of Origin (Primary) MX
Harmonized Tariff Code (Schedule B) 8708990000
Harmonized Tariff Code (HTS) 8708990000
UPC 00023913221119
VMRS Code 022003072
