Dana 6.5-4-1901-1 - 1810 Series Power Take Off (PTO) End Yoke - Steel, 6.062 C/L To End Hub S, HR Yoke Style
$44499
MSRP: $525.04
Save: $80.05
In stock
limited availability at this price!
. Learn more
DANA part description
Spicer 6.5-4-1901-1 End Yoke
6.5419011,65419011
PLEASE USE THE DANA ONILNE END YOKE CATALOG TO SELECT YOUR PART NUMBERS
6.5-4-1901-1
JOINT SERIES:1810
D DIMENSION:1.94
E DIMENSION:7.55
YOKE STYLE:Bearing Plate
Q LENGTH THRU HOLE:3
R HUB DIAMETER:3.5
S CENTERLINE TO END:6.062
SPLINE COUNT:
SPLINE OD:
NOTES:
Features & Benefits
- Genuine OE quality. Tested and proven.
- Built to meet OE standards set by Dana.
- Tested and validated to rigorous OE specifications.
- Latest production upgrades ensure genuine Spicer parts are as good or better than the OE parts they replace.
Product Attributes
| Series | 1810 |
| Material | Steel |
| Spline Count | 10 |
| Type | Splined Hole |
| Assembly | Y |
| Hub Diameter R | 3.500 IN |
| Includes Slinger/Plug | Y |
| Involute Spline | N |
| Length Thru Hole Q | 3.000 IN |
| Outside Yoke Dimension (In) E | 7.643 IN |
| Yoke Bearing Dimension (In) D | 1.938 IN |
| Yoke Style | HR |
| Major Diameter | 2.750 IN |
| C/L To End Hub S | 6.062 IN |
| Joint Angle #1 | 30 |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 8708990000 |
| Harmonized Tariff Code (HTS) | 8708990000 |
| UPC | 00023913214807 |
| VMRS Code | 025001115 |
Part Interchanges
- Elgin 45444A-30
- Cotta Transmission 80VX2248
- Daimler Truck North America 30011-3524
- Daimler Truck North America SP 6.5 4 1901 1
- Daimler Truck North America SP 6.5 4 1901 1HP
- Dana Commercial Vehicle Service Parts 2104-65419011
- Volvo 2104-65419011
- Volvo SP 65419011
- International Harvester (IHC) 1515527C1
- International Harvester (IHC) 65419011
- International Harvester (IHC) D65419011
- International Harvester (IHC) E65419011
- Navistar 1515527C1
- Navistar 65419011
- Navistar D65419011
- Navistar DS65419011
- Navistar E65419011
- Paccar Parts 6.5-4-1901-1
- Mack 2104-65419011
- Freightliner 30011-3524
- Freightliner SP 6.5 4 1901 1
- Freightliner SP 6.5 4 1901 1HP
- UAP 6.5-4-1901-1
DANA 6.5-4-1901-1 Cross Reference
We have 2 alternatives for the 6.5-4-1901-1 by DANA:
