(888) 312-8812 Login SignupDANA 5-28-167 TUBE YOKE
Tap to view 1 more
$16749
Limited availability at this price!
In Stock
Get it by Thursday, Feb 19
DANA 5-28-167 Part Description
Manufacturer
Spicer 5-28-167 1610 Weld Yoke 3.5 X .095
528167
PLEASE USE THE DANA ONILNE WELD YOKE CATALOG TO SELECT YOUR PART NUMBERS
5-28-167
SERIES:1610
F BUTT DIAMETER:3.321
H C/L TO WELD:3.000
FITS TUBE DIA:3.500
FITS TUBE WALL:
BALL STUD DIAMETER:
BALL STUD LENGTH:
JOINT CENTER TO STUD END:
528167
PLEASE USE THE DANA ONILNE WELD YOKE CATALOG TO SELECT YOUR PART NUMBERS
5-28-167
SERIES:1610
F BUTT DIAMETER:3.321
H C/L TO WELD:3.000
FITS TUBE DIA:3.500
FITS TUBE WALL:
BALL STUD DIAMETER:
BALL STUD LENGTH:
JOINT CENTER TO STUD END:
DANA 5-28-167 Specifications
Product Attributes
| Series | 1610 |
| Material | Steel |
| Design | BP |
| Fits Tube Wall (S=Seam W=Weld) | .095-WELDED |
| Joint Angle #1 | 35 |
| Butt Diameter (F) In. | 3.320 IN |
| C/L To Weld (H) In. | 3.000 IN |
| Bearing Cap Diameter (D) In. | 1.875 IN |
| Outside Yoke Dimension (E) In. | 5.312 IN |
| Fits Tube Diameter (In) | 3.500 IN |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 8708990000 |
| Harmonized Tariff Code (HTS) | 8708990000 |
| UPC | 00023913219338 |
| VMRS Code | 024002057 |
DANA 5-28-167 Cross References
| Brand | Part Number |
|---|---|
| Daimler Truck North America | SP 5 28 167, SP 5 28 167HP |
| Dana Commercial Vehicle Service Parts | 5-28-287 |
| Freightliner | SP 5 28 167, SP 5 28 167HP |
| International Harvester (IHC) | 528167, D528167, E528167 |
| MERITOR | 16N-28-167 |
| Meritor | 16N28167 |
| Navistar | 528167, D528167, DS528167, E528167 |
| Neapco OE Series | N5-28-167 |
| Paccar Parts | 5-28-167 |
| Rockwell International | 16N-28-167 |
| UAP | 5-28-167 |
| Volvo | SP 528167 |
DANA 5-28-167 Customer Reviews
No reviews yet
Be the first to review this product!
DANA 5-28-167 Manufacturer Information
Dana Holding Corporation® is an internationally known company specializing in drivetrain and e-Propulsion systems. It conceptualizes, manufactures, and supplies energy-management and power- and conveyance solutions for the present-day and future vehicles and trucks. With its over 115 years of industry experience and innovation, and despite several turbulences the automotive and trucking industry has been through, Dana has managed to take the lead in revolutionary technological inventions. Dana Holding Corporation comprises different world-renowned brands catering to various market segments. These include SPICER Drivetrain Systems, VICTOR REINZ Sealing Products, LONG Thermal Products, BREVINI Motion Systems, GRAZIANO High-Performance Transmissions, FAIRFIELD Custom Gears and Drives, and a lot more.
