(888) 312-8812 Login SignupDANA 4-2-759 1550 Series Drive Shaft Flange Yoke - Steel, 4 Bolt Holes, Rectangular Design
Tap to view 1 more
$39349
Limited availability at this price!
In Stock
Get it by Monday, Jan 12
DANA 4-2-759 Part Description
Manufacturer
Specifications
| Brand | Spicer |
| Series | 1550 |
| Flange Or Swing Dia. In. (A) | 5.875 |
| Bolt Circle Dia. In. (B) | 4.750 |
| Bolt Hole Dia. In (B) | .500 - DRILLED |
| Number Of Bolt Holes | 4 |
| Pilot Dia. M=Male F=Female (C) | 3.750 - FEMALE |
| Flange Face To C/L In. (G) | 1.500 |
| Material | Steel |
| Outside Yoke Dimension In.(E) | 5.25 |
| Yoke Bearing Dimension In. (D) | 1.375 |
| Design | Rectangular |
| Joint Angle #1 | 8 |
| VMRS | 024002016 |
| Package Type | EACH |
| Package Qty | 1 |
| Weight | 1.61 LB |
| Country of Origin | United States |
DANA 4-2-759 Specifications
Product Attributes
| Series | 1550 |
| Material | Steel |
| Number of Bolt Holes | 4 |
| Design | Rectangular |
| Bolt Circle Dia. In. (B) | 4.750 IN |
| Bolt Hole Dia. In (B) | .500 - DRILLED IN |
| Flange Face To C/L In. (G) | 1.500 IN |
| Flange Or Swing Dia. In. (A) | 5.875 IN |
| Outside Yoke Dimension In.(E) | 5.25 IN |
| Pilot Dia. M=male F=female (c) | 3.750 - FEMALE |
| Yoke Bearing Dimension In. (D) | 1.375 IN |
| Joint Angle #1 | 8 |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8708990000 |
| Harmonized Tariff Code (HTS) | 8708990000 |
| UPC | 00023913223038 |
| VMRS Code | 024002016 |
DANA 4-2-759 Part Interchanges
| Brand | Part Number |
|---|---|
| Ingersoll Rand | 931285C1 |
| Daimler Truck North America | SP 4 2 759HP |
| Dana Commercial Vehicle Service Parts | 2104-42759 |
| Dresser | 931285C1 |
| Volvo | 2104-42759, SP 42759 |
| International Harvester (IHC) | 42759, 931285C1, D42759, E42759 |
| Navistar | 42759, 931285C1, D42759, DS42759, E42759 |
| Paccar Parts | 4-2-759 |
| Mack | 2104-42759 |
| Freightliner | SP 4 2 759HP |
| UAP | 4-2-759 |
DANA 4-2-759 Cross References
We have 2 alternatives for the 4-2-759 by DANA:
DANA 4-2-759 Customer Reviews
No reviews yet
Be the first to review this product!
DANA 4-2-759 Manufacturer Information
Dana Holding Corporation® is an internationally known company specializing in drivetrain and e-Propulsion systems. It conceptualizes, manufactures, and supplies energy-management and power- and conveyance solutions for the present-day and future vehicles and trucks. With its over 115 years of industry experience and innovation, and despite several turbulences the automotive and trucking industry has been through, Dana has managed to take the lead in revolutionary technological inventions. Dana Holding Corporation comprises different world-renowned brands catering to various market segments. These include SPICER Drivetrain Systems, VICTOR REINZ Sealing Products, LONG Thermal Products, BREVINI Motion Systems, GRAZIANO High-Performance Transmissions, FAIRFIELD Custom Gears and Drives, and a lot more.
