Name: Meritor 04 15673 003 AY-REAR HUB
SKU: 0415673003
Price: 519.49 USD
Availability: InStock

MERITOR part description

ABS Pilot Diameter	6.195/6.192 in.
ABS Ring Number	3237J1258
Axle Application	Drive
Axle Series	L
Base Part Number	15673
Brake Type	Drum
Drive Flange Stud	08-205741
Drive Stud Pattern	12
Drive Stud Thread	1/2-13 UNC-3B
DriveStud Bolt Circle Dia	5.25 in.
Drum Bolt Circle Diameter	11.25 in.
Drum Bolt Pattern	10
Drum Bolt Size	.904/.906 in.
Drum Pilot Diameter	8.778/8.775 in.
Drum Position	Outboard
Flange Outer Diameter	13.00 in.
Fully Dressed	No
GAWR (lb)	19000
Hub Style	Conventional
Hub Type	Hub only
IBS to OBS	4.638/4.598 in.
IBS to Outer Surface	7.327/7.287 in.
Inner Bearing Surface (IBS) to Mounting Face	1.22 in.
Inner Cone	47686
Inner Cup	47620
Notes	Without Wheel Studs
Oil Seal	A1205W1349
Outer Cone	39590
Outer Cup	39520
Tone Ring	N
VMRS Code	018-002-001
Wheel Pilot Diameter	8.653/8.646 in.
Wheel Stud Bolt Circle Diameter	11.25 in.
Wheel Stud Hole	.904/.906 in.
Wheel Stud Pattern	10

Meritor Hydraulic Brake Hub Assembly

The Meritor hydraulic brake hub assembly is built for higher payload capacities and improved fuel economy. It is suitable for a wide range of trucks, trailers, and other commercial vehicle applications.

Features & Benefits

Designed for weight savings and strength for increased payload and better fuel mileage
Meets or exceeds OE specifications and federal stopping distance requirements
Advanced machining processes ensures an optimum balanced operation
Premium grade steel construction for superior durability over comparable aftermarket hubs
Click here for warranty information

Product Description

AY-REAR HUB

Product Attributes

Abs Pilot Diameter	6.195/6.192 in.
Abs Ring Number	3237J1258
Axle Application	Drive
Axle Series	L
Base Part Number	15673
Brake Type	Drum
Brand	Meritor Genuine
Drive Flange Stud	08-205741
Drive Stud Pattern	12
Drive Stud Thread	1/2-13 UNC-3B
Drivestud Bolt Circle Dia	5.25 in.
Drum Bolt Circle Diameter	11.25 in.
Drum Bolt Pattern	10
Drum Bolt Size	.904/.906 in.
Drum Pilot Diameter	8.778/8.775 in.
Drum Position	Outboard
Flange Outer Diameter	13.00 in.
Fully Dressed	No
Gawr (lb)	19000
Hub Style	Conventional
Hub Type	Hub only
Ibs To Obs	4.638/4.598 in.
Ibs To Outer Surface	7.327/7.287 in.
Inner Bearing Surface (ibs) To Mounting Face	1.22 in.
INNER CONE	47686
Inner Cup	47620
Notes	Without Wheel Studs
OIL SEAL	A1205W1349
OUTER CONE	39590
Outer Cup	39520
Pallet Quantity	10
Tone Ring	N
Weight	59.85
Wheel Pilot Diameter	8.653/8.646 in.
Wheel Stud Bolt Circle Diameter	11.25 in.
Wheel Stud Hole	.904/.906 in.
Wheel Stud Pattern	10

MERITOR 04 15673 003 Cross Reference

We have 2 alternatives for the 04 15673 003 by MERITOR:

Meritor®, whose roots could be traced back to 1909, is backed by over 100 years of industry experience plus a massive portfolio of products for various industries. In 1998, it made several acquisitions, including Volvo Trucks' heavy vehicle manufacturing operation in Sweden, Euclid Industries, and Lucas Varity's Heavy Vehicle Braking Systems division. Such investments solidify Meritor's position as the leading global supplier of brakes, axles, drivelines, transmissions, suspensions, tire inflations systems, and a whole lot of parts, hardware, and accessories for the automotive, truck, trailer, rail cars, bus and coach, and many other applications. Its "Run with the Bull" global brand identity further strengthens its commitment to provide the industry with durable products, unparalleled service and support, and continuous innovation.
