(888) 312-8812 Login SignupDANA 3-82-261 WELD YOKE
Tap to view 3 more
$37149
Limited availability at this price!
In Stock
Get it by Friday, Feb 6
DANA 3-82-261 Part Description
Manufacturer
| Series: | 1410 |
| Outside Yoke Dimension (E): | 4.188 in. |
| Bearing Cap Diameter (D): | 1.188 in. |
| Major Spline Diameter: | 1.75 in. |
| Spline Count: | 16 |
| Involute Spline: | N |
| Centerline to End of Spline (K): | 4.547 in. |
| End/Spline to Point/Rad. (R): | 2.672 |
| Spline Length (L) IN.: | 1.438 |
| Angle #1: | 9.0 |
| Style: | SR |
| Spline Hole Minor Diameter: | 1.484 |
| Spline Width: | 0.172 |
DANA 3-82-261 Specifications
Product Attributes
| Series | 1410 |
| Spline Count | 16 |
| Style | SR |
| Involute Spline | N |
| Bearing Cap Diameter (D) In. | 1.188 IN |
| Outside Yoke Dimension (E) In. | 4.188 IN |
| Centerline To End Of Splne (K) | 4.547 IN |
| Major Spline Diameter | 1.750 IN |
| Spline Length (L) In | 1.438 IN |
| Angle #1 | 9.0 |
| Spline Hole Minor Diameter | 1.484 IN |
| Spline Width | 0.172 IN |
| End/Spline To Point/Rad. (R) | 2.672 IN |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8708990000 |
| Harmonized Tariff Code (HTS) | 8708990000 |
| UPC | 00023913230302 |
| VMRS Code | 024002061 |
DANA 3-82-261 Cross References
| Brand | Part Number |
|---|---|
| Clarke | 992134 |
| Daimler Truck North America | SP 3 82 261HP |
| Dana Commercial Vehicle Service Parts | 2104-382261 |
| Freightliner | SP 3 82 261HP |
| International Harvester (IHC) | 382261, D382261, E382261 |
| Mack | 2104-382261 |
| Navistar | 382261, D382261, DS382261, E382261 |
| Paccar Parts | 3-82-261 |
| Terex | 992134 |
| UAP | 3-82-261 |
| Volvo | 2104-382261, SP 382261 |
