(888) 312-8812 Login SignupDANA 3-53-1131 Drive Shaft Midship Stub Shaft - For Use With Outboard Slip Yoke
Tap to view 1 more
$34499
Limited availability at this price!
In Stock
Get it by Tuesday, Jan 13
DANA 3-53-1131 Part Description
Manufacturer
Features & Benefits
- Dana manufactured Spicer components are designed, engineered, tested, and manufactured to meet or exceed OE requirements.
- Spicer components are engineered to meet or exceeds the performance requirements of the original factory driveline component
- Tested for unparalleled reliability
- Strength and durability for long life
| For Use With: | Outboard Slip Yoke |
| Series: | 1310-1550 |
| Material: | Steel |
| Spline Outside Diameter: | 1.5000 in. |
| Number of Splines: | 16 |
| Involute: | N |
| Fits Tube Diameter: | 4 in. |
| Fits Tube Wall: | 0.083 |
| Spline End to Brg Shoulder (Y): | 5.940 |
| Spline End to Weld (K) In.: | 7.062 |
| Spline Length (L) In.: | 4.438 |
| Shoulder Diameter (B) In.: | 1.810 |
| Shoulder Length (G) In.: | 0.875 |
| Bearing Diameter (C) In.: | 1.575 |
| Butt Diameter: | 3.845 |
| Style: | 1 |
| Bearing Diameter (Max): | 1.5752 |
| Bearing Diameter (Min): | 1.5747 |
| Bearing Diameter Length: | 1.5 |
DANA 3-53-1131 Specifications
Product Attributes
| Series | 1310-1550 |
| Material | Steel |
| Style | 1 |
| Fits Tube Diameter | 4 IN |
| Number of splines | 16 |
| Involute | N |
| Fits Tube Wall | 0.083 IN |
| Butt Diameter | 3.845 IN |
| Bearing Diameter (C) In. | 1.575 IN |
| Bearing Diameter (Max) | 1.5752 IN |
| Spline End To Weld (K) In. | 7.062 IN |
| Spline Length (L) In. | 4.438 IN |
| Spline O.D. | 1.5000 IN |
| Bearing Diameter (Min) | 1.5747 IN |
| For Use With | Outboard Slip Yoke |
| Shoulder Diameter (B) In. | 1.810 IN |
| Shoulder Length (G) In. | 0.875 IN |
| Spline End To Brg Shoulder (y) | 5.940 |
| Bearing Diameter Length | 1.5 IN |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 8708990000 |
| Harmonized Tariff Code (HTS) | 8708990000 |
| UPC | 00023913236939 |
| VMRS Code | 024002060 |
DANA 3-53-1131 Part Interchanges
| Brand | Part Number |
|---|---|
| Daimler Truck North America | SP 3 53 1131HP |
| Volvo | SP 3531131 |
| International Harvester (IHC) | 3531131, D3531131, E3531131 |
| Navistar | 3531131, D3531131, DS3531131, E3531131 |
| Rockwell International | BS-S24-48 |
| Freightliner | SP 3 53 1131HP |
| UAP | 3-53-1131 |
